Technical Specifications
and Warranties
SaFETY
Subject to the standard terms and conditions of sale (a copy of which has been
provided to you), neither Waterlogic International Limited ("Waterlogic"), nor any
affiliated companies shall be liable for any damage which could affect, directly or
indirectly, any person or property.
Please be aware that any warranties accompanying the sale of our products will
be invalidated by any of the following:
• Incorrect installation
• Incorrect use of the WL Max
• Unsuitable electrical and water supply
• Major short-coming of maintenance
• Technical interventions or alterations of an unauthorized nature
• Adoption and use of unapproved spare parts
• Engagement of untrained personnel
Waterlogic has a policy of constant and continual improvement and therefore
reserves the right to change specifications without prior notice, other than in the
case of significant changes.
22
Description
WL Max 1 Water Distribution WL Max 2 Water Distributions
W 321 mm, H 1413.5 mm,
Machine Size
D 335 mm
Machine Weight
34.5Kg
Power Supply
220-240 Volt / 50Hz
Dispense Area Height
330mm
Fan
N/A
Compressor
230V/50Hz (R134a)
UV Lamp
13W
Unit Total
300W
Refrigeration Gas R134a
165g
Cold Tank Capacity
Direct Chill
Water Connection
1/4" Hose
Minimum Water Pressure
0.26 (2.6)
Megapascal (Bar)
Maximum Water Pressure
0.32 (3.2)
Megapascal (Bar)
Recommended Water
0.3 (3.0)
Pressure Megapascal (Bar)
Minimum Incoming Flow
1.2 lpm
Rate (litres per minute)
Cold Water Dispensing
65lph
Capacity
Cold Water Temperature
5 - 8°C
W 321 mm, H 1413.5 mm,
D 335 mm
36Kg
220-240 Volt / 50Hz
330mm
N/A
230V/50Hz (R134a)
2 x 13W
313W
165g
Direct Chill
1/4" Hose
0.26 (2.6)
0.32 (3.2)
0.3 (3.0)
1.2 lpm
65lph
5 - 8°C
WL Max Technical Manual - Version 1 - May 2013
23
