Description
Model
HDMI Inputs
HDMI Outputs *
RJ-45 CAT 5/6 output *
* Outputs A and B are user configurable as either 1) HDMI out or 2) CAT 5/6
Ethernet cable output
Version
HDCP
IN/Out Connectors
RS-232 control port
Display Selection
Video Resolution
Video Data Rate
Deep Color Support
Vertical Frequency Scan Rate
Dimension
DC adapter (included)
Rackmount capable
Remote control (IR)
For Questions and support:
Email :
info@octavainc.com
URL: www.octavainc.com
Copyright© 2010 Octava Inc. All rights reserved.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LL.C
All trademarks are the sole property of their respective companies
Specifications
HDHC48MX-V1.3
4
2
8
1.3
Yes
19 pin HDMI female type-A
1
Remote, Manual, Smart Scan,RS-232
480 P, 720 I/P, 1080 I/P
6.75 Gbps
Yes
24 / 50 / 60 Hz
16.85 x 11.98 x 1.67 inch
(427.9x 304.2 x 42.3 mm)
9VDC, 2.6A
1RU, Rack mounts included
Infrared, Discrete code
Rev.A
V 1.3
Deep Color
Installation Guide
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Octava HDHC48MX-V1.3
Summary of Contents for Octava HDHC48MX-V1.3
- Page 1 For Questions and support: Email : info@octavainc.com URL: www.octavainc.com Copyright© 2010 Octava Inc. All rights reserved. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LL.C All trademarks are the sole property of their respective companies...
-
Page 2: Table Of Contents
Table of contents 1. Application Diagram 2. Features 3. Configuring Smart Scan 4. Installation 5. Connecting Using CAT 5/6 outputs 6. Front Panel Control 7. Remote Control Guide 8. EDID Configuration 9. Changing EDID mode 10. RS232 Controls 11. Configuring Outputs for HDMI or RJ-45 12. -
Page 3: Application Diagram
Application Diagram Features: Watch ANY 4 HD programs simultaneously on 8 Displays! V1.3, 1080P 4 HDMI inputs 8 CAT 5/6 Outputs. 2 configurable to HDMI Matrix allows 65,356 viewing combinations 1 RU mountable RS-232 control ... -
Page 4: Configuring Smart Scan
Configuring Smart Scan The Smart Scan is disabled before shipment. It is recommended to leave Smart Scan disabled in most applications. To enable the Smart Scan 1) Set the Configuration switch #1 to the up position. 2) Re-power the matrix. To disable Smart Scan 1) Set the Configuration switch #1 to the down position. - Page 5 I.R. Remote Control over CAT 5/6: Front View Display LED Indicators Infrared Detector Infrared Manual Select Jack Back View CAT5/6 output (To RECEIVER) DC Power Transmitter Input RS232 HDMI Input EDID & Smart Scan HDMI Output Switch (To TV) IR remote signals can be carried over the CAT 5/6 cables to control the 1) matrix and 2) video sources.
-
Page 6: Installation
Installation: Configuring Outputs for HDMI or RJ-45 : Output ASCII Command Mode 1) Verify that the Configuration Switch is in the factory default mode. <STX>911<ETX> HDMI mode <STX>912<ETX> RJ-45 CAT 5/6 mode <STX>921<ETX> HDMI mode <STX>922<ETX> RJ-45 CAT 5/6 mode 2) Connect the DC power adapter 3) Configure output A and B to either 1) HDMI OR 2) RJ-45 CAT 5/6 output. -
Page 7: Source Display Switching
Source Display Switching: Connecting Using CAT 5/6 outputs: Output-Input ASCII Command Function Selection Configure the output to CAT 5/6 output ( see page 7) <STX>211<ETX> Select OUT A to Input port 1 Connect CAT5e -1 of the HDMI Matrix and Receiver with CAT5e/6 <STX>212<ETX>... - Page 8 Front Panel Control: RS232 Controls: The Octava 4x8 HDMI - CAT 5/6 Matrix Switch can be easily integrated Source Selection: with 3 Party control systems via RS232 control. The following shows You may use the front panel buttons to select the sources connected to each the control protocol for controlling the HDHC48MX.
- Page 9 Remote Control Guide: Press the A button LED will flash on the front panel. “0" Pressing A-H LED will flash”0” for while Selects the Display ~2 min while programming. to be controlled. programming. Wait. Programming is Pressing 1-4 Pressing +/- complete when LED Selects the Increments/Decrements...
- Page 10 EDID Configuration: Changing EDID mode: It is recommended to keep the EDID in the factory default MODE1. If necessary, you may set to different EDID mode by following these The Matrix can be configured to 3 EDID settings. instructions. It is recommended to keep the EDID in the default factory mode 1. Mode Video Audio...
