Installation Instructions
Model Numbers:
MCVP42N, MCVP42NE, MCVP42LP, MCVP42LPE
ANSI Z21.50-2014 • CSA 2.22-2014
ZERO CLEARANCE VENTED GAS FIREPLACE
Model Numbers:
MCVP42NH, MCVP42NHE, MCVP42LPH, MCVP42LPHE
ANSI Z21.88-2014 • CSA 2.33-2014
ZERO CLEARANCE VENTED GAS FIREPLACE HEATER
Certified to:
Certified to:
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For Propane Horizontal installations the
venting must be an additional one foot
above the minimum vertical rise off the flue
This appliance may be installed in an
aftermarket, permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
before going horizontal.
ATRIUM
A Division of R-Co. Inc.
2340 Logan Ave.
Winnipeg, Manitoba Canada
R2R 2V3 Ph.: (204) 632-1962
Printed in Canada May 5, 2015
Part# 42MCVP-MAN14
Advertisement
Table of Contents
Related Manuals for Marquis Atrium MCVP42NH
Summary of Contents for Marquis Atrium MCVP42NH
-
Page 1: Installation Instructions
Installation Instructions Model Numbers: MCVP42N, MCVP42NE, MCVP42LP, MCVP42LPE Certified to: ANSI Z21.50-2014 • CSA 2.22-2014 ATRIUM ZERO CLEARANCE VENTED GAS FIREPLACE Model Numbers: MCVP42NH, MCVP42NHE, MCVP42LPH, MCVP42LPHE Certified to: ANSI Z21.88-2014 • CSA 2.33-2014 ZERO CLEARANCE VENTED GAS FIREPLACE HEATER This appliance may be installed in an aftermarket, permanently located, manufactured home (USA only) or mobile... -
Page 2: Table Of Contents
Table of Contents INFORMATION Table of Contents…………………………………………………………………………………………………………... Glass Safety / Termination Cap Safety- All Units……………………………………………………………………………... Warnings, Installations, and Operations……………………………………………………………………………………….. Pre-installation Questions and Answers……………………………………………………………………………………….. Operating Instructions……………………………………………………………………………………………………………. Recommendations for Finishing of Clean View Installations…………………………………………………………..Mobile Home/Manufactured Housing Installation…………………………………………………………………………….. MCVP42 INSTALLATION Framing- Nailing Tab Guide……………………………………………………………………………………………………... Framing Your Gas Fireplace…………………………………………………………………………………………………….. - Page 3 IPI SECTION IPI Electronic Ignition System……………………………………………………………………………………………... Remote Control Operation………………………………………………………………………………………………………. IPI Electronic Ignition Parts List – Standard System…………………………………………………………………………. Configuration 1: Basic Manual Hi / Lo and manual Off………………………………………………………………………. Configuration 2: Remote On / Off and manual Hi / Lo……………………………………………………………………….. Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls……………………………… Configuration 3: Remote ON/OFF, Variable HI/LO, and Fan………………………………………………………………...
-
Page 4: Glass Safety / Termination Cap Safety- All Units
-Glass Safety- All Units IT IS THE RESPONSIBILITY OF THE HOME OWNER TO ENSURE THAT NO ONE TOUCHES A HOT APPLIANCE. If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance. Any safety screen, guard, or barrier removed for servicing the appliance, must be replaced prior to operating the appliance. -
Page 5: Warnings, Installations And Operations
Warnings, Installations and Operations Installation Regulations This gas appliance must be installed by a qualified installer in accordance with local building codes, or in the absence of local codes, with the current CAN/CSA-B149.1 or .2 Installation Code (in Canada) or the current National Fuel Gas Code Z223.1- NFPA 54 when installed in the United States. This appliance, when installed, must be electrically connected and grounded in accordance with local codes, or in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code or with the National Electrical Code;... -
Page 6: Operations And Maintenance Instructions
Gas fired appliances may be used only for supplemental heat and/or decorative purposes and under no circumstances shall they provide a primary heat source. This appliance must not be connected to a chimney flue serving a separate solid-fuel burning appliance. NOTE: It is recommended that a Carbon Monoxide (CO) Detector be installed in or near bedrooms and on all levels of your home. -
Page 7: Pre-Installation Questions And Answers
Pre-installation Questions and Answers About curing of the paint Your stove or fireplace has been painted with the highest quality silicone stove paint. This paint dries quickly in 15-20 minutes when first applied at the factory. However, due to the high temperature silicone components, the paint will cure when heat is applied to the appliance as it is first used. -
Page 8: Recommendations For Finishing Of Clean View Installations
Recommendations for Finishing of Clean View Installations When finishing the wall around the fireplace, it is critical that the wall covering be fastened properly. It is acceptable to pre-drill holes and use self-tapping screws which may be used to fasten a backer for tile, marble, etc. Screws being installed through non-combustible board should be self-tapping type with a maximum length of 2 inches. -
Page 9: Mobile Home/Manufactured Housing Installation
Mobile Home/Manufactured Housing Installation This Direct Vent System Appliance must be installed in accordance with the manufacturer’s installation instructions and the Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240 MH Mobile Home Standard in Canada. -
Page 10: Framing- Nailing Tab Guide
MCVP42 Framing- Nailing Tab Guide [Qty] 4 Nailing Tabs are located on flue side of fireplace. These Nailing Tabs can be used in two ways: 1/2” Drywall Flush with Face of Fireplace – Framing Flush with Face of Fireplace -Fireplace to be covered Fireplace and Combustible Wall to be covered with Non-Combustibles (e.g. -
Page 11: Framing Your Gas Fireplace
MCVP42 Framing Your Gas Fireplace This section is intended for qualified installers only. Before beginning, make note of where the gas and electrical accesses are located on the unit. This will streamline the construction process. Furthermore, familiarize yourself with the venting and clearance requirements (see Venting section) for this appliance. -
Page 12: Locating Your Appliance / Fireplace Dimensions
MCVP42 Locating Your Appliance See Mantel Leg Clearances Instruction for the proper placement of fireplace. PENINSULA ISLAND ALL UNITS MAY BE VENTED VERTICALLY MCVP42 Fireplace Dimensions... -
Page 13: Framing Dimensions
MCVP42 Framing Dimensions These structures are not load bearing. Optional- floor cutout for gas line if Framed fireplace opening. coming up through floor. TOP VIEW Vent Framing (Vertical or Horizontal) Vertical Venting MUST maintain 1” clearance to combustibles. 9” Round Hole through Masonry. 12”... -
Page 14: Facing Requirements
MCVP42 Facing Requirements Required Non-Combustible Areas If you are covering the face of the fireplace: NOTE: MATERIALS COVERING THE FACE OF THE FIREPLACE MUST BE NON-COMBUSTIBLE It is also recommended to attach Non-combustible facing to framing. Note: Do not drive excessively long screws into the face of the unit as internal parts may be damaged. Combustibles (i.e. -
Page 15: Basic Finishing Mcvp42
Basic Finishing MCVP42 Step One: Frame Fireplace with nailing tabs oriented as Step Two: Use Drywall to finish face of wall. shown. NOTE: Drywall will be flush with fireplace face. Drywall Fireplace Frame Fireplace Frame Nailing Tab Step 3: A brick, tile, or other non-combustible border may be applied over fireplace face to conceal border. Drywall Tile Fireplace Frame... -
Page 16: Mantel Clearances
MCVP42 Mantel Clearances Before installing any mantels it is important to determine the combustibility of its material(s). There are two types of mantels to consider: Combustible and Non-Combustible. A Combustible Mantel is one that consists of material(s) that may discolor, combust, or lose its integrity in the presence of heat. -
Page 17: Clearance To Combustibles
MCVP42 Clearance to Combustibles Clearance to Combustibles MCVP42 24” Front and Sides 0” Back (from Stand-offs) 0” Floor* *Note: If appliance is installed directly on carpeting or other combustible material other than wood flooring, a metal or wood panel extending the full width and depth of the appliance must be used. Carpet may extend 1 inch above the floor of the appliance. -
Page 18: Safety Screen Installation
MCVP42 Child Safety Screen Installation Contents of Kit: [3] Child Safety Screens- Ready to Install Assembly Instructions: Attach screen to fireplace as per instructions below. NOTE: Screens are symmetrical from top to bottom. ⚠ WARNING: Wait until unit is COMPLETELY cool before touching glass or attempting to install or remove Child Safety Screens. -
Page 19: Mp42Pl Porcelain Liner Installation
MP42PL Porcelain Liner Installation ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. Instructions: (NOTE: Porcelain Liners should be installed BEFORE Log Grates or Glass Tray.) Step One: Remove Main Burner (refer to Burner Removal section). -
Page 20: Mp42Rl Brick Liner Installation
MP42RL -Brick Liner Installation- When using M42LG Log Grates NOT FOR USE WITH MP42GT. NOTE: Brick Liner must be installed BEFORE MP42RL Consists of: M42LG is installed. [1] – Back Liner NOTE: Either Baffle (Heater Rated Units) or Deflectors (Decorative Units) must be removed. Refer to Baffle Removal / Deflector Removal sections of manual. -
Page 21: Baffle Removal (Heater Rated Units) / Deflector Removal (Decorative Units)
ZCV42MCVP Baffle Removal (Heater Rated Units) To Remove Baffle: Remove [5] DT Screws holding Baffle in place. NOTE: Remove end screw last. See below. To Replace Baffle: Hook Mount Tab onto ledge at top of firebox. Replace end screw first. Replace [4] remaining screws. -
Page 22: Mp42-Gt Installation / Removal
MP42-GT Installation / Removal 42MCVP Contents of Kit: 1 Glass Tray NOT FOR USE WITH MP42RL. Instructions: ⚠ To Install: Place Glass Tray into NOTE firebox as shown. Pilot Area Must Not Be Covered, as delayed ignition can occur. To Remove: Lift Glass Tray from one edge and carefully remove. -
Page 23: M42-Lg Installation / Removal
M42-LG Installation / Removal 42MCVP Contents of Kit: 1. [2] Log Grates 2. [2] Large Bags 3/4” Lava Rock 3. [3] 350 Embers 4. [1] Vermiculite 5. [1] Insulation Wool 6. [1] Grate Plate 7. [6] DT Screws Instructions: To Install: 1. -
Page 24: Mq42Log1 8 Piece Driftwood Log Set - For Use With Gt Glass Tray
MQ42LOG1 8 Piece Driftwood Log Set - For use with GT Glass Tray ⚠ PILOT WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. -
Page 25: Mq42Log1 8 Piece Driftwood Log Set - For Use With M42Lg Log Grate
MQ42LOG1 8 Piece Driftwood Log Set - For use with M42LG Log Grate Place 350 Embers from M42LG in PILOT Burner Tray Place Insulation Wool from M42LG in Burner Tray Place Lava Rock from M42LG on Grates and Firebox Bottom Place Vermiculite from M42LG on Grates and Firebox Bottom... -
Page 26: Mq42Log2 7 Piece Oak Log Set - For Use With Gt Glass Tray
MQ42LOG2 7 Piece Oak Log Set - For use with GT Glass Tray PILOT ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. -
Page 27: Mq42Log2 7 Piece Oak Log Set - For Use With M42Lg Log Grate
MQ42LOG2 7 Piece Oak Log Set - For use with M42LG Log Grate PILOT Place 350 Embers from Place M42LG in Insulation Burner Tray Wool from M42LG in Burner Tray Place Lava Place Rock from Vermiculite M42LG on from M42LG Grates and on Grates Firebox... -
Page 28: M42Log3 6 Piece Driftwood Log Set - For Use With Gt Glass Tray
M42LOG3 6 Piece Driftwood Log Set - For use with GT Glass Tray PILOT ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal... -
Page 29: M42Log4 8 Piece Oak Log Set - For Use With M42Lg Log Grate
M42LOG4 8 Piece Oak Log Set - For use with M42LG Log Grate PILOT Place 350 Place Insulation Embers from Wool from M42LG M42LG in in Burner Tray Burner Tray ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this... -
Page 30: Uhs Box / Component Locations
MCVP42 51UHS Box Included with base model. The 51-UHS Box is designed for millivolt and IPI units for in-unit installation of the Remote Receiver, Fan Control Module, and the IPI Module. 51-UHS Box can be inserted & removed from beneath fireplace through access panel opening (Remove glass door first). NOTE: When using a remote control, the 51-UHS Box must be used. -
Page 31: Ulk3 Universal Light Kit
ULK3 Universal Light Kit ( Optional Accent Lighting Kit) MCVP42 & MCVST42 Please follow the current ANSI/NFPA 70 National Electrical Code in the USA and CAN/CSA C22.1 Canadian National Electrical Code in Canada. Contents of Kit: Inside Firebox [2] 12V Halogen Lamps ... -
Page 32: Split Receptacle- Switch Control Outside Of Fireplace
Split Receptacle- Switch Control Outside of Fireplace If you wish to have a control switch outside of the fireplace for one side of the receptacle and you require a constant source of AC power inside the unit for another accessory such as lights or an IPI valve system, follow one of the procedures below. -
Page 33: Rbcb1 -Cannonballs- Installation Instructions
RBCB1 -Cannonballs- Installation Instructions *Must be used with MST42GT/ MP42GT Glass Tray Assorted size and colors. Place randomly as desired inside fireplace. PILOT Can be used with MQ Glass, MQ Ember, and / or Lava Rock. Do not place Cannonballs directly on burner ports. If sooting occurs change position of or remove affected objects. -
Page 34: Mq Dealer Accessories For Mcvst42 / Mcvp42 (Glass)
MQ Dealer Accessories for MCVST42 / MCVP42 The following Accessories are available through MQ Dealers only. GLASS (MQG5W, MQG5C, MQG5A, MQG5B, MQG5ZG) ACCESSORY ITEM DESCRIPTION If you wish to use this media evenly spread the glass embers onto the false bottom and burner. -
Page 35: Mqstone, Mqrock, Mqember
MQ STONE / MQ ROCK- Must be used with MST42GT/ MP42GT Glass Tray The following Accessories are available through MQ Dealers only. MQ STONE DECORATIVE STONE SET- Must be used with Glass Tray MST42GT/ MP42GT PILOT NOTE Pilot Area Must Not Be Covered, as delayed ignition can occur. -
Page 36: Door Installation
ZCV39 / ZCV42 / MCVST42 / MCVP42 Door Installation To install Door: 1. Remove Access Cover below Glass Door. 30° 15° 2. Engage door in lower latches at an angle of between 15 and 30 degrees. 3. Swing door up and pull top latches over door lip at each corner. ⚠... -
Page 37: Door And Glass Information
Door and Glass Information MCVP42 Glass Cleaning It will be necessary to clean the glass periodically. During startup, condensation, which is normal, forms on the inside of the glass, and causes dust, lint etc. to cling to the glass surface. Also, initial paint curing can deposit a slight film on the glass. -
Page 38: Gas Line Installation
Gas Line Installation This gas appliance should be installed by a qualified installer in accordance with local building codes and with current CAN/CGA - B149.1 or .2 installation codes for Gas Burning appliances and equipment in Canada and the National Fuel Gas Code ANSI Z223 in the U.S.A. -
Page 39: Millivolt System, Lighting, And Burner Control
Millivolt System, Lighting, and Burner Control FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING This appliance has a pilot which must be lighted by hand. When Immediately call your gas supplier from a neighbour’s phone. -
Page 40: Troubleshooting The Gas Control System
Troubleshooting the Gas Control System WARNING BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE THE GLASS FRONT. Before troubleshooting the gas control system, be sure external gas shut off is in the "On" position. Problem Possible Causes Corrective Action Spark igniter will not light. Defective or misaligned Check for spark at electrode and pilot: if no spark and electrode wire is electrode at pilot. -
Page 41: Burner System Maintenance
Burner System Maintenance- MCVST42 / MCVP42 It is recommended to annually inspect and clean the Burner System to prevent malfunction and / or sooting. This operation should be performed by your dealer or a qualified technician. -CAUTION- Before servicing the burner system ensure that the gas supply is turned OFF and disconnect all electrical connections to the appliance. -
Page 42: Conversion Kit Instructions - Part A
Gas Conversion Part A MCVP42 Models: MCVP42LP, MCVP42N, MCVP42LPE, MCVP42NE Description Pilot Orifice Burner Orifice Brass Nipple Air Shutter Hi/Lo Regulator Kit Number Brass (1000-255) 42MP-CKLP LP Conversion 1001-P167SI 1000-253 Fully Open 1001-P202SI -Millivolt- #30 (977.167) Closed (0.907.202) 1/16” 42MP-CKNG NG Conversion 1001-P165SI 1000-253... -
Page 43: Gas Conversion Kit For Top Convertible Pilot Part B
installationinstructions gas conversion kit for top convertible pilot series 0190XYZ) Instructions for converting SIT 190 series pilot burner injector from NG to LPG and from LPG to NG only. This information should be considered as supplemental to the Appliance Manufacturer's Instructions. Warning! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer. -
Page 44: Gas Conversion For Modulator - Part C
Gas Conversion for Modulator – PART C WARNING!- WARNING!-... -
Page 45: Main Burner Removal / Burner System Removal / Installation
MCVST42 / MCVP42 Main Burner Removal If Glass Tray or Log Grates are installed, refer to MCVST42GT or MCVST42LG Installation / Removal page in this manual. To remove burner, Lift Pilot Shield off of Pilot. Remove four [4] screws from burner. Slide burner away from pilot and lift to remove. -
Page 46: Ipi Electronic Ignition System
IPI Electronic Ignition System Overview The IPI system is an advanced burner controller that Cover provides you with the option of having either a Standing- Pilot, or an intermittent igniting system. This alternating Backup mode is controlled by the CPI/IPI Switch (Continuous Pilot Battery Ignition/Intermittent Pilot Ignition) located on the IPI System Pack... -
Page 47: Remote Control Operation
-Remote Control Operation- The Proflame GTM is configured to control the on/off main burner operation, its flame levels, and provides on/off and Smart thermostatic control of the appliance. Transmitter Remote Receiver Transmitter Room Thermostat ( Transmitter Operation) The Transmitter is powered by 3 AAA type batteries. A Mode The Remote Control can operate as a room thermostat. -
Page 48: Ipi Electronic Ignition Parts List - Standard System
IPI Electronic Ignition Parts List – Standard System ITEM NO. PART NO. DESCRIPTION 1006-P002si Valve IPI Hi/Lo NG 1006-P003si Valve IPI Hi/Lo LP *1002-P047si Pilot Assembly-LP -24” Wire *1002-P033si Pilot Assembly-NG -24” Wire 1002-P017si Spark Electrode (with wire) *1002-P119si Spark Electrode (with wire- 35” Length) 1002-P903si Electrode Flame Sensor *1002-P910si... -
Page 49: Configuration 1: Basic Manual Hi / Lo And Manual Off
Configuration #1: Basic Manual HI/LO and Manual ON/OFF Capabilities... -
Page 50: Configuration #2: Remote On/Off And Manual Hi/Lo
Configuration #2: remote ON/OFF and Manual HI/LO Optional: For units with remote HI/LO capabilities a modulating servo is required to be installed on the valve. The connectors to this servo must be connected to the Remote Harness as shown in the figure below. -
Page 51: Operating The Receiver Without Batteries For Gt / Egt / Gtm / Egtm Remote Controls
Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls -Wiring Harness P/N 1002-P906si required for both IPI & Millivolt systems. -Millivolt Systems will also require Power Adapter P/N 1002-P850si. The Remote Receiver & IPI or Millivolt system can be powered by the AC Adapter. This is advantageous if you do not want to use batteries. -
Page 52: Configuration 3: Remote On/Off, Variable Hi/Lo, And Fan
Configuration #3: Remote ON/OFF, Variable HI/LO, Lights and Fan NOTE: FAN IS NOT AVAILABLE ON 42MCVP UNITS. -
Page 53: Electronic Ignition Lighting Instructions
Electronic Ignition Lighting Instructions If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Always light the pilot whether for the first time or if the gas supply has ran out with the glass door opened or removed. FOR YOUR SAFETY READ BEFORE LIGHTING: A. -
Page 54: Vent Termination
Vent Termination WARNING: WHEN THE HORIZONTAL VENT TERMINATION IS ACCESSIBLE A CERTIFIED GUARD (SAFETY CAGE) SHALL Measure to the edge of the termination plate. BE INSTALLED. Measure to the edge of the round termination. N - Clearance to perpendicular wall 24 inches (60 cm). Vent Terminal (Recommended to prevent re-circulation of exhaust products. -
Page 55: General Vent Installation
General Vent Installation Information This gas appliance is approved to be vented either through the side wall or vertically through the roof. Only Kingsman Flex (Z-Flex) Venting Kits and components specifically approved and LABELED for this stove may be used. This appliance is also approved for use with 5 x 8 M&G-Duravent Direct Vent system (Model DV-GS Series), BDM Pro Form Direct Vent, Ameri-Vent Direct Vent Pipe System, ICC Excel Direct, Metal Fab Sure-Seal DV and Selkirk Direct Temp. -
Page 56: Venting Routes And Components
Venting Routes And Components Venting Routes and Components Since it is very important that the vent system maintain its How to Use the Horizontal Vent Table balance between the combustion air intake and the flue gas 1. Determine the height of the system and the number of exhaust, certain limitations as to vent configurations apply and bends required. -
Page 57: Z58Ht Horizontal Installations- Wall Thimble Sizing / Termination Sizing
Z58HT Horizontal Installations- Wall Thimble Sizing / Termination Sizing- NOTE: If you are installing 5/8 Termination in an existing wall, measure diameter of both Wall Thimble and Termination. Wall Thimble mount plate comes in two sizes: Termination Plate comes in two sizes: 13-5/16”... - Page 58 New Wall Thimble Old Wall Thimble Old Termination Old Termination 13-3/4" Wall Thimble Wall Thimble 15-3/4" Termination Termination 13-5/16" 13-5/16" 1-3/16" 3/16" Old Wall Thimble New Termination New Wall Thimble 15-3/4" New Termination Wall Thimble Wall Thimble 13-3/4" 14-5/16" 14-3/8" 11/16"...
-
Page 59: Venting Straight Up Through Roof
Venting Straight Up Through Roof An Attic Insulation Shield must be installed where the vent passes from a lower living space into an attic space where the chimney is not enclosed. It is designed to keep insulation materials away from the chimney. When installing the Attic Insulation Shield where the chimney passes from a living space to an attic space, install the shield from below and nail in place using 1"... - Page 60 -Restrictor- Remove for Runs Under 15 Feet Clearances in horizontal venting. Z58VT 43ft Straight-through roof support configuration; b) Flex bend configuration; c) Termination mounting...
-
Page 61: Approved For Power Vent Pvh58
Approved for Power Vent PVH58 The PVH58 Horizontal Power Vent is approved for the following models only: MDV31, MDV39, MQRB3632, ZDV3622, MQZDV3622, ZDVRB3622, HBZDV3624, HBZDV3628, HBZDV3632, MQHBZDV3636, HBZDV4224, HBZDV4228, HBZDV4232, MQHBZDV4236, HBZDV4740, MQHBZDV4736, MQRB4436, MQRB5143, MQRB6961, ZRB46, ZCV39, ZCV42, MCVP42, MCVST42, MQZDV3927*, MQZDV4634* *NOTE: For MQZDV3927 and MQZDV4634, Power Vent Control Module (PVCM) must be placed outside of Fireplace. -
Page 62: Pvh58 Parts List
PVH58 Parts List PVH58 HORIZONTAL POWER VENT TERMINATION: Listed for Canada and USA NUMBER DESCRIPTION MCVP42 & MCVST42 VENTING AND VENTING ADAPTERS -For fireplaces to be converted to hard pipe (M&G-Duravent-DirectVent Pro, etc.) at the fireplace: Z58DFA M&G-Duravent Fireplace Adapter -For Power Vent installations where flex pipe will be used up to the Power Vent unit: Z58PVA Flex Connector Set- ZDV5FC (5”... -
Page 63: Mcvp42 Parts List
MCVP42 Parts List Door Glass Fireplace Part Numbers 42HB-310 Tempered Glass-for Decorative MCVP42N (Millivolt) Fireplace Decorative rated, Units NG, Tempered Glass, Safety Screens 42HB-311 Ceramic Glass-for Heater Rated MCVP42NH (Millivolt) Fireplace Heater rated, NG, Ceramic Glass, Safety Screens Units MCVP42NE (IPI) Fireplace Decorative Rated NG, 42MCVP-315T Tempered Glass-for Decorative... - Page 64 Control Variable Speed KBWC- 1000-085 Remote Control / Millivolt 13BV Remote Control Millivolt / IPI – On/Off GFRC FP15GC Stainless Steel Gas Connector GTRC Remote Control Millivolt - Thermostat Remote Control Millivolt – GTMRCN Thermostat/Modulating - NG KINGSMAN FIREPLACE VENTING Remote Control Millivolt –...
-
Page 65: Limited Lifetime Warranty
This Limited Lifetime Warranty applies only while the unit remains at the site of the original installation and only if the unit is installed inside the continental United States, Alaska, Hawaii, and Canada. The warranty applies only if the unit is installed and operated in accordance with the printed instructions and in compliance with applicable installation and building codes and good trade practices.
