Advantech ASMB-310IR Startup Manual

ASMB-310IR/310 (Dual 1366 Socket CEB Server Board with
2 PCIe x16 Expansion Slots)
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 x ASMB-310IR/310 CEB moth erboard
2. 1 x ASMB-310IR Startup Manual
3. 1 x Driver CD (user's manual is included)
4. 2 x Serial ATA HDD data cables
5. 2 x LGA 1366 2U/4U CPU Cooler
6. 1 x I/O port bracket
7. 2 x SATA power cable
8. 1 x Warranty card
If any of these items are missing or damaged, please contact
your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
adobe.com/Prodindex/acrobat/readstep.html (Ac-
robat is a trademark of Adobe).
General
For more information on this and other Advantech prod-
ucts, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our sup-
port website at:
http://service.advantech.com.tw/support/
This manual is for the ASMB-310IR Series Rev. A1.
Part No. 2006310R11
Printed in Taiwan
Specifications
• PCIe architecture: The Intel E5520 PCH chipset supports
36 PCIe lanes
• Intel latest dual processor platform: ASMB-310IR/310
support two Intel Latest 5500/5600 Quad/Dual core Pro-
cessor
• High performance I/O capability: Dual Gigabit LAN via
PCIe x1 bus, one PCIe x4 slot, 6 SATAII connectors and
11 USB 2.0 ports
• Standard CEB form factor with industrial features:
ASMB-310IR provides industrial features like long prod-
uct life, reliable operation under wide temperature range,
watchdog timer, etc
• SAS hard drive support: Embedded LSI 1068E SAS
controller which can support eight SAS/SATA HDD with
software RAID 0,1,1E (for ASMB-310IR only)
• IPMI 2.0 support: ASMB-310IR equip Aspeed 2050 BMC
chip supports IPMI 2.0 (Intelligent Platform Management
Interface 2.0) via dedicated LAN port
• KVM over IP: ASMB-310IR KVM over IP function
www.
Graphic Interface
• Controller: ASPEED AST2050 controller with 64 MB VGA
memory provides basic

Ethernet Interface

• LAN1: 10/100/1000 Mbps GbE LAN Intel 82574L
• LAN2: 10/100/1000 Mbps GbE LAN Intel 82567LM

Mechanical and Environmental

• Dimensions: 304.8 x 257.05 mm
• Operating temperature: 0 ~ 50° C
The board has a number of jumpers that allow you to con-
figure your system to suit your application.
2 Edition
nd
Sept. 2011
ASMB-310IR Startup Manual 1
