Display when using the heart rate option

If the heart rate option is activated, the current heart rate
is shown on the left of the display.
If the heart rate option is activated the indicator arrows
show whether the heart rate is below or above the selected
training zone.
The current gradient uphill/downhill, which is displayed at this
point if the heart rate option is not activated, is now shown at
the top right of the display.
The temperature can now be accessed via the menu within
the bike functions by pressing the BIKE button.

Button allocation with the heart rate option

If the heart rate option is activated, the heart rate functions
can be accessed by pressing the TPC (TOTAL/PULSE/CAD)
button.
When the heart rate option is activated, the TPC
(TOTAL/PULSE/CAD) button has the following functions:
TPC (TOTAL/PULSE/CAD)
In function mode:
– Access the heart rate functions
(scroll forwards through the functions)
– Select the heart rate training zone
(press and hold)
In setting mode:
– Scroll in the setting menu (backwards)
– Change the data to be set (decrease)
