Intel
Server Systems
SR4850HW4M and SR6850HW4M

Configuration Guide

Rev 2.77
A reference guide to assist customers in ordering components to configure a Harwich 800T-based server system.
RoHS compliance w/ server exemption
SR4850HW4M = Harwich 800T/Granby 4U Server
SR6850HW4M = Harwich 800T/Gilbert 6U Server
12/7/2007
SR4850HW4M / SR6850HW4M Configuration Guide
Page 1 of 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR6850HW4M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Intel SR6850HW4M

  • Page 1: Configuration Guide

    A reference guide to assist customers in ordering components to configure a Harwich 800T-based server system. RoHS compliance w/ server exemption SR4850HW4M = Harwich 800T/Granby 4U Server SR6850HW4M = Harwich 800T/Gilbert 6U Server 12/7/2007 SR4850HW4M / SR6850HW4M Configuration Guide Page 1 of 12...
  • Page 2: Table Of Contents

    3. Important Notes ........................3 4. System Configuration Options ....................4 5. 4U System Part Configurator: SR4850HW4M..............5 6. 6U System Part Configurator: SR6850HW4M..............6 7. Base System SKU Configuration Contents................7 Table 1 : Base System Product Code Contents............7 8. Complete Product Ordering Code Listings ................8 Table 2 : Base System Codes..................8...
  • Page 3: Revision History

    9. The SRx850HW4M memory board supports DDR2 400 SDRAM registered DIMMs. 10. The Intel factory will package board orders into single order packaging and ship to fill customer orders. Each board MM is a self-contained shipping package of one board.
  • Page 4: System Configuration Options

    LCD Control Supply Blank Professional Advanced Panel Panel Optional Accessories Rack Rails and ROMB Key and Fibre Channel Up to 3 additional Pedestal Kit (6U) Bezels Battery Module memory boards. 12/7/2007 SR4850HW4M / SR6850HW4M Configuration Guide Page 4 of 12...
  • Page 5: U System Part Configurator: Sr4850Hw4M

    Fibre Channel Module AHWFCMOD Rack rails AXXRAIL3U7U Rack Mount Solutions Cable Management Arm AXXCMA3U7U 4 DIMM memory board Memory board BHW4DIMMM 4U Front bezel for rack mount Front Bezel AHW4URBEZEL 12/7/2007 SR4850HW4M / SR6850HW4M Configuration Guide Page 5 of 12...
  • Page 6: U System Part Configurator: Sr6850Hw4M

    6U System Part Configurator: SR6850HW4M Mandatory Accessories Feature Product IMM Professional Intel Management Module AHWIMMPRO2 IMM Advanced (Choose one per System) AHWIMMADV2 Button control panel Control Panel AXXBCPMOD2 LCD control panel (Choose one per System) AXXLCPMOD2 Processor heat sink Processor...
  • Page 7: Base System Sku Configuration Contents

    1x Sample Safety Label • 1x System Serial # Label • 1x System Packaging • 1x Rack Handles (Pair) Intel® Server Platform SR6850HW4M (Harwich 800T). 6U Rack. • 1x Baseboard • 1x Front Panel IO board • 1x Memory Board (1X4) plus bracket •...
  • Page 8: Complete Product Ordering Code Listings

    Table 2: Base System Codes Image Product Code MM / Description Order SHW4URM 879454 Intel® Server Platform SR4850HW4M. SHW6URM 879452 Intel® Server Platform SR6850HW4M. 12/7/2007 SR4850HW4M / SR6850HW4M Configuration Guide Page 8 of 12...
  • Page 9 Memory board. 4 DIMM. 8 Pack. Intel CEK processor heat sink. AHWPROCHS 869848 AHWPROCBLANK 881378 Intel CEK processor blank. One required for every empty processor slot to maintain proper airflow for cooling. AHWVRMCM 883663 Processor cache VRM 9DO for Intel® Xeon™...
  • Page 10: Table 4 : 4U Unique Accessory Codes For Shw4Urm

    Rack bezel for SR6850HW4. AHW6UPBEZEL 881839 Pedestal bezel for SR6850HW4. AHW6U3SASKIT 882993 SAS 3.5" Conversion kit for SR6850HW4M (SCSI conversion to SAS) - Contains Cable, Backplane, and SAS Module(FHW6UINTSAS, FHW6U3SASBP, FXXSROMBSAS18E) 12/7/2007 SR4850HW4M / SR6850HW4M Configuration Guide Page 10 of 12...
  • Page 11: Table 6: Common System Spare Part Codes

    871422 Cable: Peripheral bay to SCSI backplane for SR4850HW4. (4 pin power) AHW4UPCISCSI 876112 Cable: 4U PCI to SCSI backplane for SR4850HW4. Cable Board FHW4USCSIBP 881456 SCSI backplane for SR4850HW4. 12/7/2007 SR4850HW4M / SR6850HW4M Configuration Guide Page 11 of 12...
  • Page 12: Table 8: 6U Unique Spare Part Codes For Shw6Urm

    Table 9: Boxed Processor Codes Reference (Heatsink Included) Category Product Code Description Boxed Processor BX805507140M 3.4 GHz/16M/800 Dual-Core Intel® Xeon™ processor 7140M series Boxed Processor BX805507130M 3.2 GHz/8M/800 Dual-Core Intel® Xeon™ processor 7130M series Boxed Processor BX805507120M 3.0 GHz/4M/800 Dual-Core Intel® Xeon™ processor 7120M series...
