  • Page 1 AtlonA PC / Laptop to HDMI Converter with built-in Scaler up to 1080p AT-HD500 User Manual...

  • Page 2: Table Of Contents

    4. Panel Descriptions ..........4.1 Front Panel ..........4.2 Rear Panel ..........5. OSD Operation ..........6. Connection Diagram ..........7. Support Resolution ..........8. Resetting the Unit ..........9. Safety Information ..........10. Warranty ..........11. Atlona Product Registration ..........

  • Page 3: Introduction

    INTRODUCTION This Scaler Box is designed to upscale analog video signal from PC input source to digital HDMI output of wide-range HDTV and PC resolutions, up to 1080p/WUXGA. Besides video upscaling, the scaler box also converts digital/analog audio signal to digital/analog format, then output to HDMI combining with the video, TOSLink (optical fiber), and phone jack (L/R audio) simultaneously.

  • Page 4: Panel Descriptions

    PANEL DESCRIPTION 1. Front Panel 1. PC Input: Connect the PC input D-Sub (15-pin) port to the D-Sub output port of your source equip- ment such like PC. 2. Audio Input: Connect the PC 3.5mm phone jack input port to the analog audio output port of your source equipment.

  • Page 5: Osd Operation

    OSD OPERATION 1 st Tier Option 2 nd Tier Option Adjustment CONTRAST 0 ~ 100 of Contrast Level BRIGHTNESS 0 ~ 100 of Contrast Level - HUE 0 ~ 100 of Hue Level FINETUNE - SATURATION 0 ~ 100 of Saturation Level - SHARPNESS 0 ~ 100 of Sharpness Level - EXIT...

  • Page 6: Connection Diagram

    CONNECTION DIAGRAM HDMI cable HDTV AT-HD500 AMPLIFIER SUPPORT RESOLUTION PC INPUT HDMI OUTPUT SD/HD 480I/576I (NTSC/PAL) 480P/576P 720P@(50/60) 1080I@(25/30) 1080P@(50/60) VGA@(60/72/75/85) SVGA@(56/60/72/75/85) XGA@(60/70/75/85) SXGA@(60/75/85) UXGA@60 WXGA@60(1280x800) WSXGA@60(1680x1050) WUXGA@60(1920x1200) RESETTING the UNIT 1. Press and hold “Menu” button for 5 seconds 2.

  • Page 7: Safety Information

    It may also cause damage to your the manufacturer could void the AT-HD500. Opening the product will void the user’s authority to operate this warranty. equipment.

  • Page 8: 10. Warranty

    Product, or repair or replacement of the Product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication.

  • Page 9: 11. Atlona Product Registration

    At Atlona, we respect and protect your privacy and assure you that your registration information is completely secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited warranty rights. To register go to www.atlona.com/registration...
