G A L A X Y N A S L X 2 C O N F I G U R A T I O N
1.3

Model Variations

1.3.1 Description of Physical components

1.3.2 Component specifications

The GalaxyNASLX2 16 bay is a 3U 16-bay rack mountable network appliance server
and storage enclosure that supports up to sixteen hot-swappable hard disk drives. The
cpu board is an ATX, dual Zeon server mother board. This board supports:
•
One 3.2Ghz ZEON CPU, option for two CPUs plus Dual core
•
On board Linux OS Flash boot drive, Slim CD, Slim FDD
•
On board externally connected printer, video, mouse, and keyboard
•
On board dual 1Gb Ethernet ports
•
Ships with 2GB DDR RAM
•
Up to 6 PCI-X slots
•
PCI-X SATA II RAID 6 controller
15
A N D
Floppy drive Front panel and system control
CD Rom drive RAID Disk drives and trays
S Y S T E M I N T E G R A T I O N G U I D E
Section 1 Intro and Overview
