● Terminals of PV inverter
Caution !
About SF-SW. Risk of electric shock！Only authorized personnel is
allowed to set the DIP switch.

3.3 Dimension and Weight

● Dimension
10
RS485
DC Input
Figure 3 Terminals of PV inverter(1.5 kW~2.8 kW)
RS485
DC Input
Figure 4
Terminals of PV inverter(3.3 kW~5 kW)
332mm
Figure 5 SR1K5TLA1/SR2K2TLA1/SR2K8TLA1
SF-SW
AC Output
RS232
SF-SW
AC Output
RS232
161mm
