1 Installing the server blade into the enclosure

Overview

The HP Integrity BL860c i2 Server Blade is a dense, low-cost, Intel® Itanium® processor server
blade. Using a Scaleable Blade Link hardware assembly, multiple BL860c i2 Server Blades can
be conjoined to create dual-blade four socket and quad-blade eight socket variants.
Name
BL860c i2
BL870c i2
BL890c i2
The three blade configurations support the HP-UX operating system and are designed for
deployment in c-Class enclosures, specifically the 10U c7000 and the 6U c3000 Enclosures.
NOTE: For purposes of this guide, make sure that the c-Class server blade enclosure is powered
on and running properly and that the OA iLO is operational.

Server blade overview

Product
BL860c i2
BL870c i2
BL890c i2

Server blade dimensions and weight

NOTE: These specifications are for the BL860c i2 Server Blade.
Dimensions
Height
Width
Depth
Weight
Number of Conjoined Server Blades
1
2
4
CPU cores (quad) DIMM slots
8 24
16 48
32 96
value
36.63 cm (14.42 in.)
5.14 cm (2.025 in.)
48.51 cm (19.1 in.)
Unloaded: 8.6 kg (19 lb)
Fully loaded: 11.3 kg (25 lb)
Number of CPU Sockets
2
4
8
PCIe I/O
Mezzanine card
max memory capacity
192GB with 8GB 3
DIMMs
384GB with 8GB 6
DIMMS
768GB with 8GB 12
DIMMS
SAS Hard Disk
Drives
2
4
8
