NOTE:
3. Ensure the DIMM slot latches are open.
CAUTION:
adversely affect data integrity.
DIMMs do not seat fully if turned the wrong way.
DIMMs in a pair or quad must be identical.
4. Insert a DIMM in a slot and push down firmly until the latches click shut.

Installing mezzanine cards

Optional mezzanine cards enable additional network connectivity and provide Fibre Channel
support. For mezzanine card locations, see
Optional mezzanine cards are classified as Type I mezzanine cards and Type II mezzanine cards.
The card type determines where it can be installed in the server blade:
• Install Type I mezzanine cards on any mezzanine connector.
• Install Type II mezzanine cards only on Mezzanine 2 connector or Mezzanine 3 connector.
To install a card:
30 Installing the server blade into the enclosure
The server blade ships with at least two DIMMs installed in slots 3A and 4A.
Use only HP low profile (1.2 in.) DIMMs. DIMMs from other sources might
"Server blade components" (page 8).
