SUV Cable and Ports
The SUV port on the front of the server blade is used in conjunction with an SUV cable to connect
the server to external devices such as a terminal emulator or monitor.
CAUTION:
Use caution when walking near the server blade when the SUV cable is installed. Hitting or
bumping the cable might cause the port on the server blade to break. This can damage the system
board.
Server blade
1
Video
2
Rear panel view
Power connectors
1
16
Installing the server blade into the enclosure
The SUV cable is not designed to be used as a permanent connection.
3
2
USB ports (2)
GBX signal connectors
Serial
4
