- Page 1 Installation, Operation, Maintenance, & Troubleshooting Model: LGD, Drop-In Griddle Lang Manufacturing Company 6500 Merrill Creek Parkway Everett, WA 98203 Rev. # A Phone: 425-349-2400 Fax: 425-349-2733 ETL File# 68964 WWW.LANGWORLD.COM © Copyright 2003...
- Page 2 THE INFORMATION IN THIS MANUAL IS CRUCIAL AND MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. DANGER POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH. POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT WARNING AVOIDED, COULD RESULT IN DEATH OR SERIOUS INJURY.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER PAGE 1. TABLE OF CONTENTS ................3 2. READ FIRST ....................4 3. EQUIPMENT DESCRIPTION ..............6 4. UNPACKING ....................6 5. INSTALLATION................... 7 6. INITIAL START-UP ..................13 7. OPERATION ....................14 8. CLEANING & MAINTENANCE PROCEDURES........15 9. -
Page 4: Read First
IMPORTANT READ FIRST IMPORTANT CAUTION THE GRIDDLE IS EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE PLACE OF INSTALLATION. - Page 5 Any cleaner used should be marked: “SAFE ON ALUMINUM”. NOTICE Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your authorized service station directory or call the factory at 1-800-224-LANG (5264), or WWW.LANGWORLD.COM For the service station nearest you.
-
Page 6: Equipment Description
If concealed loss or damage is discovered upon unpacking, make a written request for inspection by the carrier's agent within 15 days of delivery. All packing material should be kept for inspection. Do not return damaged merchandise to Lang Manufacturing Company. File your claim with the carrier. -
Page 7: Installation
INSTALLATION DANGER THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED. FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION AND DEATH. WARNING INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY. IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. - Page 8 INSTALLATION CONT’D LGD24 Cabinet Cut-out ETL File# 68964 REV. A...
- Page 9 INSTALLATION CONT’D LGD36 Cabinet Cut-out ETL File# 68964 REV. A...
- Page 10 INSTALLATION CONT’D LGD48 Cabinet Cut-out ETL File# 68964 REV. A...
- Page 11 INSTALLATION CONT’D LGD60 Cabinet Cut-out ETL File# 68964 REV. A...
- Page 12 INSTALLATION CONT’D LGD72 Cabinet Cut-out ETL File# 68964 REV. A...
-
Page 13: Initial Start-Up
INITIAL START UP NOTICE During the first few hours of operation you may notice a small amount of smoke coming off the unit, and a faint odor from the smoke. This is normal for a new griddle and will disappear after the first few hours of use. Pre-Power On Before turning the griddle on verify all electrical connections and remove excess shipping grease from the griddle surface. -
Page 14: Operation
OPERATION CAUTION ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM COMBUSTIBLE MATERIALS. CAUTION KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR FALLS. An understanding of how the griddle sections are controlled will be a valuable aid in loading your griddle. -
Page 15: Cleaning & Maintenance Procedures
Always start with a cold griddle. Always follow the cleaner manufacturer's instructions when using any cleaner. Griddle surface may be cleaned using Lang Mfg. Carbon Release (72804-32) cleaner. Always apply these cleaners when the griddle is cold and rub in the direction of the metal's grain. -
Page 16: Troubleshooting
Product is burning Thermostat out of calibration • Defective thermostat Service on this, or any other, LANG appliance must be performed by NOTICE qualified personnel only. Consult your authorized service station directory or call the factory at 1-800-224-LANG (5264), or WWW.LANGWORLD.COM For the service station nearest you. -
Page 17: Parts Lists
PARTS LIST DESCRIPTION PART NO. Griddle Element 208 / 240-Volt O/S 4500 Watts / 6000 Watts 11030-29 Griddle Element 208-Volt I/S 1491 Watts 11030-30 Griddle Element 480-Volt 5991 Watts 11030-31 30402-08 Thermostat 450° F 30402-07 Thermostat 550° F 70701-19 Knob Thermostat 450°F 70701-15 Knob Thermostat 550°F Indicator Lamp 240-Volt... -
Page 18: Wiring Diagrams
WIRING DIAGRAM 208/240- VOLT ETL File# 68964 REV. A... - Page 19 WIRING DIAGRAM 480 VOLT ETL File# 68964 REV. A...
