1.
Click a desired tab.
2.
Enter information or select from the list for each parameter.
Adding Settings to Provider Profiles
Follow the steps below to add the settings to provider profiles.
1.
Click Add Provider.
A dialog box will appear. Available virtual SIP gateway port numbers are displayed in the list.
2.
Highlight the desired port numbers or click Select All to select all the virtual SIP gateway port numbers to
add the settings to provider profiles.
3.
Click Execute.

3.1.1 Main

Slot
Indicates the slot position (reference only).
Default
Current slot number
Value Range
Slot number
Port
Indicates the port number (reference only).
Default
Current port number
Value Range
Port number
Connection
Indicates the port status.
This column offers two ways to open the screen to select the port command:
•
Click the desired cell in the column.
•
Select the desired cell in the column, and then click Command.
Default
Current status
Value Range
INS: The port is in service.
OUS: The port is out of service.
Fault: The port is not communicating with the network.
Channel Attribute
Specifies the channel property of each port to enable several sessions to be performed for one subscription
with the SIP provider.
