Menu #2 - Advanced Features; Feature Descriptions; Menu #1 - Basic Features - Clifford Matrix +1 Installation Manual

menu #2 - Advanced Features

Feature One Chirp
Number Setting
Siren
2-1
30-second siren duration
2-2
False Alarm Control Technology ON FACT II ™ OFF
2-3
Progressive door trigger
2-4
Valet switch input: 1 pulse
2-5
Bypass Notification ON
2-6
Ignition-controlled domelight ON
2-7
Single unlock pulse
2-8
Single lock pulse
2-9
Channel 3: Validity
2-10
2-11 Comfort Closure (On) (20 sec.)
*The Bitwriter allows programming from 1-180 seconds.
*Second unlock is only available if Feature 2-8 is programmed to single pulse.

Feature Descriptions

The features of the system are described below. Features that have additional
settings that can be selected only when programming with the 998T Bitwriter
are indicated by the following icon:

menu #1 - Basic Features

1-1 ACTIVE/PASSIVE ARMING:
system will only arm when the transmitter is used. When set to passive, the
system will arm automatically 30 seconds after the last door is closed. To alert
the consumer of passive arming, the siren will chirp 20 seconds after the door is
closed. This provides the consumer with an audible prior to the system actually
arming. At the 30 second mark, the system will arm but the siren will not
chirp.
1-2 Chirps ON/OFF:
arming and disarming of the system.
22
When active arming is selected, the
This feature controls the chirps that confirm the
© 20 0 8 D i re cte d E l ec tro n i cs- Al l ri g ht s res e r v e d.
Two-Chirp
Setting
Horn honk
60-second siren duration*
Instant door trigger
Valet switch input: 2-5 pulses
Bypass Notification OFF
Ignition-controlled domelight OFF
Double unlock pulse
Double lock pulse
Channel 3: latched/latched, reset
with ignition/30-second timed/
second unlock output*
Comfort Closure (Off)
