Door Lock Harness (H2), 3-PIN Connector

Green
___
H2/A
Empty
___
H2/B
Blue
___
H2/C
ImPORTANT! The door lock outputs are low current and should not
be attached directly to any high current device; they are only to be
used to activate relays.
For detailed instructions about connecting to the vehicle's power door lock
systems, refer to the Door Lock Wiring guide (Document No. 1041) available
to authorized dealers only from the technical resources listed at the front of
this guide.
11
(-) Lock, (+) Unlock Output
Unless Using 451m
(-) Unlock, (+) Lock Output
