Plug-In LED and valet/program switch

The LED and the valet switch are incorporated into the Control Center. The
LED line plugs into the WHITE 2-pin port, and the valet switch plugs in to
the BLUE 2-pin port.
NOTE: The onboard LED can be substituted with an optional outboard
LED (P/N 8634 for Blue LED and 8633 for red LED). The LED fits into a
9/32 inch mounting hole. Be sure to check for clearance prior to drilling the
mounting hole.
You can also substitute an external valet switch for the Control Center valet
switch (P/N 8631 is a 5-pack of these switches)
Important! With the Control Center more customers will want the Ghost
switch coded disarm feature - make sure to check with the customer.
12
Valet switch
© 20 0 8 D i re cte d E l ec tro n i cs- Al l ri g ht s res e r v e d.
LED
