Motor Locks
Motor locks secure the door using a hardened steel motorised
deadbolt. When the correct unlocking signal is received the bolt
withdraws, allowing the door to open.
The benefits of motor locks include:
Provide an extremely high level of security that can
be controlled and monitored from a remote location.
Secure serial encrypted communication between the control
unit and the lock ensures maximum resistance to compromise.
A single unit solution; their external appearance is the same as
a conventional lock and they may be fitted with door furniture
to match other doors in the building.
On activation
*
* Motor retracts deadbolt
Operating Format
If there is a power failure the door will remain in the state it was in previously: either locked
or unlocked.
Compatibility
The 810S, 811S, 8000S and 8001S are compatible with conventional ASSA Modular mechanical
locks. The 811S/35mm and 8087S are for narrow stile doors.
Each motor lock is supplied as standard with striking plate, magnetic sensor, 6m cable, and DAC-30
control unit. The control unit may in turn be linked to any host control system, switch or timer.
