Smart Technologies Smart Board Plasma Display Installation Manual page 25

5. Select the amount of time you want to intervene between screen saver activation and the
initiation of standby mode by clicking the up or down arrow button in Delay Time. The
default delay time is one minute.
6. Click the Install button.
The plasma display model you selected will be listed under the Serial Port in the On-
Screen Controller Installer dialog box.
7. Click the Start button.
The On-Screen Display Controls dialog box for your plasma display will immediately
appear together with an icon in the System Tray as shown below.
8. If you don't have a screen saver installed, activate SMART Bulb Saver as explained in the
next section of this guide. The On-Screen Display Control that automatically puts your
plasma display into sleep mode during periods of inactivity will not work unless you have a
screen saver installed.
To activate SMART Bulb Saver:
1. Click the Start button in the Task Bar, point to Settings and then select Control Panel.
The Windows Control Panel directory will appear.
2. Double-click on Display.
The Display Properties dialog box will appear.
3. Click on the Screen Saver tab.
4. Click the scroll-down arrow under Screen Saver and select SMART Bulb Saver.
5. Click the Settings button.
The SMART Bulb Saver dialog box will appear. The set of On-Screen Display Controls that
you configured for your plasma display will be listed under Display.
6. To use your own custom bitmap or company logo as the SMART Bulb Saver graphic, click
on the Custom tab and browse to the graphic file you want to use.
7. To shut down the computer and log off the current user, click on the Shut Down tab and
follow the instructions in that dialog.
8. Click the OK button in the SMART Bulb Saver dialog box.
The Display Properties dialog box will reappear.
9. Click the OK button in the Display Properties dialog box.
On-Screen Display Controls Icon
SBPD Installation Guide
21
