2. Slide the SBPD over the plasma display. There will be a slight gap on each side.
3. Place the two upper-corner mounting brackets in place, guiding the brackets onto the
threaded studs on the overlay.
SBPD Overlay
Plasma Display
Guiding the Mounting Brackets onto the Threaded Studs
Sliding the SBPD over the Plasma Display
SBPD Installation Guide
Plasma Display
SBPD
Threaded
Studs
Corner Mounting
Bracket
11
