Identifying jam areas

The following illustration shows the path that print media travels through the printer. The path varies depending on the input
sources you are using.
200 Paper Jam
Check Area I
200 Paper Jam
Check Area H
Clearing jams
200 Paper Jam
Check Areas A,B
200 Paper Jam
Check Area G
200 Paper Jam
Check Area D
T 1
T 2
T 3
T 4
241 Paper Jam
242 Paper Jam
243 Paper Jam
244 Paper Jam
Identifying jam areas
250 Paper Jam
96
200 Paper Jam
Check Areas C
200 Paper Jam
Check Area F
249 Paper Jam
T 3/T 5
(depending on
configuration)
200 Paper Jam
Check Area E
