Reinstalling the system board access cover
After you finish installing cards on the printer system board, reinstall the system board access cover.
1
Align the holes on the access cover with the screws on the printer.
Hole
2
Place the cover against the printer and slide it down.
3
Tighten the eight screws.
Aligning the optional high capacity feeder
Note: Failure to properly align the high capacity feeder may cause paper jams.
