Installing height adjustment spacers
If the pins on the high capacity feeder do not align with the holes in the docking frame, adjust the height of the feeder.
You can either remove the factory installed spacer or add two spacers between each caster and the bottom of the high
capacity feeder.
Use the following steps to add or remove spacers.
1
Determine the height difference between high capacity feeder alignment pins and the docking frame.
2
Place the high capacity feeder on the floor or adequate work surface.
3
Remove the four screws securing one of the casters to the high capacity feeder.
4
Add or remove spacers.
To add spacers:
a Insert the four screws through the caster.
b Place the spacers on the screws.
Installing and removing options
Aligning the optional high capacity feeder
35
