Color quality guide
This Color Quality guide helps users understand how operations available on the printer can be used to adjust
and customize color output.

Quality Menu

Selections available in the Quality Menu provide the user with multiple options that can adjust color characteristics
of the printer.
Values marked by an asterisk (*) are the factory default settings. Values selected in the printer PostScript or PCL
emulation drivers for Windows will override printer settings.
Menu item
Purpose
To determine whether images are printed in
Print Mode
a monochrome grayscale or in color.
To adjust the printed color to better match
Color
the colors of other output devices or
Correction
standard color systems.
Due to the differences between additive and
subtractive colors, certain colors that
appear on the monitor are impossible to
duplicate on the printer.
To lighten or darken printed output, or
Toner
conserve toner.
Darkness
To conserve toner in graphics and images
Color Saver
yet maintain high quality text. The amount of
toner used to print graphics and images is
reduced; however, text is printed with
default toner usage. If selected, this setting
overrides Toner Darkness settings. Color
Saver is not supported in PPDS, and
partially supported by the PCL emulation
driver.
Color quality guide
Page 1 of 7
Values
Color*
Black Only
Auto*
Applies different color conversion
tables to each object on the
printed page, depending on the
type of object and how the color for
each object is specified.
Off
No color correction is
implemented.
Manual
Allows customization of the color
conversion tables applied to each
object on the printed page,
depending on the type of object
and how the color for each object
is specified. Customization is
performed using the selections
available under the Manual Color
menu item.
4*, 5
Darkest output, no reduction in
toner consumption
3
Reduction in toner consumption.
2
Further reduction in toner
consumption.
1
Maximum reduction in toner
consumption.
On*
Off
