Installing an option card
Your printer has one expansion card slot that supports a number of option cards. The following table describes their
function.
Card
MarkNet N8000 series internal print
server
Serial/Parallel 1284-C Interface Card
Coax/Twinax Adapter Card for SCS
802.11g Wireless Print Adapter
Note: The network models ship with an Ethernet print server already installed.
You need a small Phillips screwdriver to install these options.
1
Remove the system board access cover (see Removing the system board access cover).
2
Remove the screw from the metal plate that covers the connector slot, and then lift the plate off.
Save the screw.
Warning:
Option cards are easily damaged by static electricity. Touch something metal, such as the printer
frame, before you touch an option card.
3
Unpack the option card.
Save the packing materials.
Installing and removing options
Function
Adds an Ethernet, Token-Ring, or Fiber port to connect your printer to a
network.
Adds an RS-232C serial and 1284-C parallel interface port.
Adds a coaxial/twinaxial network port.
Connects to an optional MarkNet N8000 series internal print server to add
US or international 802.11g wireless printing capability.
Installing an option card
