From the remote control:
DVD DVD MULTI
VCR 1 VCR 2
TV/DBS VIDEO
Note:
Once you have selected a video source, pictures of the selected
source are sent to the TV until you select another video source.
Speaker and signal indicators on the display
By checking the following indicators, you can easily confirm which
speakers you are activating and which signals are coming into this
receiver from the source.
Speaker indicators (white)
L C R
SUBWFR
LS RS
The speaker indicators
The indicators correspond to the speakers as follows:
Frame Speaker
L Left front
R Right front
C Center
LS Left rear
RS Right rear
Subwoofer
SUBWFR
The signal indicators
The signal indicators light in the following cases:
• When the DIGITAL input mode (see page 31) is selected, only the
indicators for the incoming signals light.
• When the ANALOG input mode (see page 31) is selected, the
indicators light as follows:
- When selecting "DVD MULTI" (see pages 9 and 49), all the
signal indicators except "S" always light on the display.
- When selecting the sources other than "DVD MULTI," only "L"
and "R" always light on the display.
To bring out the best performance of this receiver, check the
speaker and signal indicators on the display carefully and set the
speakers correctly.
L C R
LFE
Ex.The center signals are coming
LS RS
19
PHONO CD
TAPE/MD CDR
FM/AM USB AUDIO
Signal indicators (red)
L C R
LFE
LS S RS
It always lights while the main
room is activated.
It lights when you set the
corresponding speaker correctly.
(For details, see page 29.)
It always lights when
"SUBWOOFER" is set to "YES."*
(For details, see page 28.)
from the source, but the center
speaker is not prepared.
Notes:
• "S" is the monaural rear signal. It is automatically mixed down to
"LS" and "RS."
• "LFE" signals are automatically mixed down to the other signals
when you select the digital input mode. However, when you select
"DVD MULTI," this receiver reproduces the LFE signals only
through subwoofer channel.
* When you do not press SUBWOOFER OUT ON/OFF to deactivate
the subwoofer.

Adjusting the Main Room Volume

On the front panel:
To increase the volume, turn MASTER VOLUME clockwise.
To decrease the volume, turn it
counterclockwise.
• When you turn MASTER VOLUME
rapidly, the volume level also changes
rapidly.
• When you turn MASTER VOLUME
slowly, the volume level also changes slowly.
From the remote control:
To increase the volume, press VOLUME +.
To decrease the volume, press VOLUME –.
CAUTIONS:
• Always set the volume to the minimum before starting any source. If
the volume is set at its high level, the sudden blast of sound energy
can permanently damage your hearing and/or ruin your speakers.
• Be careful not to turn up the volume so high when controlling the
receiver without listening to the playback sound. For example, when
adjusting the volume level in the sub-room from the main room.
Notes:
• The volume level can be adjusted within the range of "0" (minimum)
to "90" (maximum).
• If you set One Touch Operation to "ON" (see page 34), you do not
have to adjust the volume level each time you change the source. It
is automatically set to the stored level for the previous setting.

Activating the Main Room Front Speakers

When shipped from the factory, both pairs of the front speakers have
been set to be used in the main room.
• To use the front speakers connected to the FRONT 2/SUB ROOM
SPEAKERS terminals for the sub-room, see "Setting the Front
Speakers Either for the Main Room or Sub-room" on page 27, and
"Activating the Sub-room Front Speakers" on page 26.
IMPORTANT:
You can activate two pairs of the front speakers at the same time only
when the SPEAKER LOAD SELECTOR switch on the rear panel is
set to the "HIGH" position and when no signals are sent to the center
and rear speakers. Otherwise, activating one pair of the speakers
deactivates the other.
MASTER VOLUME
VOLUME
