Basic Operating Procedure for Sub-Room

The sources and functions available for the sub-room
operations are limited.
For more details on the sub-room operations, see "Sub-Room
Operations" on pages 23 to 26.
On the front panel:
1. Press POWER.
The STANDBY lamp on the front panel
goes off, and the MAIN ROOM indicator
lights on the display.
• For more details, see "Turning the Power On and Off
(Standby) and Selecting the Sub-room Operations" on page
23.
The sound comes out of the speakers in the main room, and the
buttons and controls on the front panel work for the main room
operations.
2. Press SUB ROOM ON/OFF so that
the SUB ROOM indicator lights on
the display.
The sound comes out of the front speakers in the sub-room.
If no sounds come out of the front speakers, press
SPEAKERS ON/OFF SUB ROOM so that the SPEAKERS
SUB ROOM indicator lights on the display.
• See also "Setting the Front Speakers Either for the Main
Room or Sub-room" on page 27, and "Activating the Sub-
room Front Speakers" on page 26.
Note:
If the center speaker or rear speakers are used for the Surround/
DSP modes (see page 37) for the main room operations,
the SPEAKERS ON/OFF SUB ROOM button does not work.
3. Press SUB ROOM CONTROL so
that "SUB" and the previously
selected source name for the sub-room
appear on the display.
Now the buttons and controls on the front panel work for the
sub-room operations.
4. Select and play a source.
DVD MULTI DVD VCR 1
PHONO CD CDR
Notes:
• You cannot select DVD MULTI as a source for the sub-room.
• When the source name of TV SOUND/DBS is assigned to "TV
SOUND," TV SOUND/DBS buttons does not work. To change
the source name, see "Changing the Source Name" on page 33.
STANDBY
POWER
SUB ROOM ON /OFF
SUB ROOM CONTROL
VCR 2 VIDEO TV SOUND/DBS
SOURCE NAME
TAPE / MD USB AUDIO FM / AM
SOURCE NAME
5. Turn MASTER VOLUME to adjust the volume
level of the sound from the front speakers in the
sub-room.
From the remote control:
1. Set MAIN ROOM/SUB ROOM selector to "SUB
ROOM."
MAIN ROOM
Now the buttons and controls on the remote control work for the
sub-room operations.
2. Press AUDIO POWER ON.
The STANDBY lamp on the front panel goes off, and the SUB
ROOM indicator lights on the display.
• See also "Turning the Power On and Off (Standby) and
Selecting the Sub-room Operations" on page 23.
STANDBY
The sound comes out of the front speakers in the sub-room.
If no sounds come out of the front speakers, press
SPEAKERS ON/OFF SUB ROOM on the front panel so that the
SPEAKERS SUB ROOM indicator lights on the display.
• See also "Activating the Sub-room Front Speakers" on page
26.
Note:
If the center speaker or rear speakers are used for the Surround/
DSP mode (see page 37) for the main room operations,
the SPEAKERS ON/OFF SUB ROOM button does not work.
3. Select and play a source.
DVD DVD MULTI
VCR 1 VCR 2
TV/DBS VIDEO
Notes:
• You cannot select DVD MULTI as a source for the sub-room.
• When the source name of TV SOUND/DBS is assigned to "TV
SOUND," TV SOUND/DBS buttons does not work. o change the
source name, see "Changing the Source Name" on page 33.
• See also "Operating the Playback Source for the Sub-room" on
page 26.
4. Press VOLUME +/– to adjust the volume level of
the sound from the front speakers in the sub-
room.
VOLUME
MASTER VOLUME
SUB ROOM
ON
PHONO CD
CDR
TAPE/MD
USB AUDIO
FM/AM
