  • Page 1 JAZZY 1121 32 Wedgwood Road • Bicester, Oxon OX26 4UL...
  • Page 2 On the product, this icon is represented as a black symbol with a red circle and red slash. NTENDED The intended use of the Pride Mobility Products device is to provide mobility to persons limited to a seated position that have the capability of operating a powered wheelchair. Quick Reference Information...

  • Page 3: Table Of Contents

    SAFETY ..............................5 III. YOUR POWER CHAIR ........................13 IV. ASSEMBLY ............................17 COMFORT ADJUSTMENTS ......................21 VI. BATTERIES AND CHARGING ..................... 32 VII. CARE AND MAINTENANCE ......................36 VIII. WARRANTY ............................41 APPENDIX I - SPECIFICATIONS ......................42 Jazzy 1121 www.pridemobility.com...

  • Page 4: Introduction

    I . I N T R O D U C T I O N SAFETY WELCOME to Pride Mobility Products (Pride). The power chair you have purchased combines state-of-the-art components with safety, comfort and styling in mind. We are confident that these design features will provide you with the conveniences you expect during your daily activities.

  • Page 5: General Guidelines

    Check the brakes. See VII. “Care and Maintenance.” Check battery charge. See VI. “Batteries and Charging.” Ensure the manual freewheel levers are in drive mode before sitting on the power chair. NOTE: If you discover a problem, contact your authorised Pride Dealer for assistance. Jazzy 1121 www.pridemobility.com...

  • Page 6: Your Power Chair

    Do not attempt to negotiate obstacles with the seat in a reclined position unless an attendant is present to help stabilise the chair. Failure to heed may result in the power chair tipping over. www.pridemobility.com Jazzy 1121...
  • Page 7 If you feel that you may tip over in a corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your power chair from tipping. WARNING! When cornering sharply, reduce your speed and maintain a stable centre of gravity. This greatly reduces the possibility of a tip or fall. Jazzy 1121 www.pridemobility.com...
  • Page 8 2. Increase the forward speed just before the front wheels come in contact with the obstacle. 3. Reduce the forward speed only after the rear wheels have cleared the obstacle. Figure 2. Correct Kerb Approach Figure 3. Incorrect Kerb Approach www.pridemobility.com Jazzy 1121...

  • Page 9: Stairs And Escalators

    WARNING! Always be sure your power chair and its batteries are properly secured when it is being transported. Batteries should be secured in an upright position and protective caps should be installed on the battery terminals. Batteries should not be transported with any flammable or combustible items. Jazzy 1121 www.pridemobility.com...

  • Page 10: Positioning Belts

    Movements such as these may change your centre of gravity and the weight distribution of the power chair. This may cause your power chair to tip. www.pridemobility.com Jazzy 1121...
  • Page 11 WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or if you have certain physical limitations. Some medications and limitations may impair your ability to operate your power chair in a safe manner. Jazzy 1121 www.pridemobility.com...
  • Page 12 NOTE: For further information on EMI/RFI, go to the Resource Centre on www.pridemobility.com. If unin- tended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Contact Pride to report the incident. www.pridemobility.com Jazzy 1121...

  • Page 13: Assembly

    SEATBACK JOYSTICK ARMREST SEAT ASSEMBLY CONTROLLER (REMOTE PLUS SHOWN) SEAT BASE BODY SHROUD POWER BASE ASSEMBLY CASTOR WHEEL FRONT RIGGING (FOOT PLATFORM DRIVE WHEEL SHOWN) ANTI-TIP WHEELS Figure 5. The Jazzy 1121 Jazzy 1121 www.pridemobility.com...
  • Page 14 (UNDERNEATH ELECTRONICS TRAY) ONBOARD BATTERY CHARGER (UNDERNEATH ELECTRONICS TRAY) MOTOR/BRAKE ASSEMBLY Figure 6. The Jazzy 1121 Power Base CONTROLLER CONNECTOR (VSI SHOWN) CHARGER INHIBIT CONNECTOR CHARGER FUSES (UNDER COVER) MAIN CIRCUIT BREAKER AMMETER CHARGER POWER LEAD RECEPTACLE Figure 7. The Jazzy 1121 Electronics Tray www.pridemobility.com...
  • Page 15 VSI controller use a 3-pin connector. Not shown. Active-Trac Suspension The Jazzy 1121 is equipped with Active-Trac Suspension (ATS). ATS is a suspension system designed to make your power chair traverse different types of terrain and obstacles while maintaining smooth operation. With ATS, the front anti-tip wheels work in conjunction with your motor suspension to help you manoeuvre over obstacles in excess of 7.62 cm (3 in.) in height.
  • Page 16 Figure 9. Freewheel Mode (Drive Disengaged) Figure 9a. Drive Mode (Drive Engaged) NOTE: If the lever is difficult to move in either direction, rock your power chair back and forth slightly. The lever should then move to the desired position. www.pridemobility.com Jazzy 1121...

  • Page 17: Initial Assembly

    Replacement nylon insert lock nuts are available at local hardware stores or through your authorised Pride Dealer. ARMREST ADJUSTMENT SEAT INSTALLATION SEAT HEIGHT/ANGLE ADJUSTMENT CONTROLLER POSITION FOOT PLATFORM ADJUSTMENT ANTI-TIP WHEEL ADJUSTMENT Figure 10. Jazzy 1121 Assembly View Jazzy 1121 www.pridemobility.com...
  • Page 18 9. Use a wire tie to secure the controller harness to the armrest. 10. Plug the controller harness into the connector on the power base. SEAT TOWER CONTROLLER MOUNT SEAT POWER RECEIVER BASE RETAINING CLIP Figure 11. Euro Seat Installation/Removal www.pridemobility.com Jazzy 1121...
  • Page 19 SEAT LATCH SAFETY SEAT LATCH SAFETY REAR TRAPEZE BAR REAR EXTRUSION FRONT TRAPEZE BAR POWER SEAT BASE FRICTION LOCK FRONT EXTRUSION Figure 12. Universal Mounting System Figure 12a. Universal Mounting System (Power Seat) Jazzy 1121 www.pridemobility.com...
  • Page 20 7176-19 transport of an occupied power chair in a motor vehicle. Indicates power chair securement points. TO UTILITY TRAY Figure 13. Harness Routing SECUREMENT BRACKETS Figure 13a. Transit System Securement Brackets www.pridemobility.com Jazzy 1121...

  • Page 21: Comfort Adjustments

    Your authorised Pride Dealer has evaluated your power chair and made any necessary adjustments to suit your specific requirements. Do not change your seating configuration without first contacting Pride Mobility Products Ltd. or your authorised Pride Dealer.
  • Page 22 1. Loosen the securement screw located on the bottom of the armrest receiver bracket. 2.Slide the armrest in or out to the desired position. 3. Tighten the screw to secure the armrest. Figure 17. Armrest Width Adjustment www.pridemobility.com Jazzy 1121...
  • Page 23 10. Tighten the button head screws to secure the controller in the figure 8 clamp. 11. Use wire ties to secure the controller harness and the manual recline lever cable to the armrests. 12. Plug the controller into the power base. Jazzy 1121 www.pridemobility.com...
  • Page 24 10. Remove each screw from the trapeze bars and apply thread lock. 11. Reinstall each screw into the trapeze bars and tighten. 12. Reinstall the seat. 13. Reconnect the controller to the power base. RETAINING CLIPS Figure 21. Trapeze Bar Adjustment www.pridemobility.com Jazzy 1121...
  • Page 25 1. Remove the adjusting screws on both seat hinges. See figure 23. SEATBACK ANGLE 2. Set the seatback at the desired angle. ADJUSTING 3. Reinstall the screws on both seat hinges and tighten. SCREW ARMREST KNOB Figure 23. Seatback Angle Adjustment Jazzy 1121 www.pridemobility.com...
  • Page 26 1. Flip up the armrest so it is perpendicular to the floor. 2. Loosen the setscrew on the controller bracket. See figure 24. 3. Slide the controller into or out of the armrest to the desired position. www.pridemobility.com Jazzy 1121...
  • Page 27 You can adjust the angle of the foot platform with a hex key. See figure 26. To adjust the foot platform angle: 1. Locate the setscrew on the underside of the foot platform. 2. Turn the setscrew to raise or lower the front of the foot platform. Jazzy 1121 www.pridemobility.com...
  • Page 28 3. Raise or lower the anti-tip bracket. 4. Reinstall the nut and bolt on the anti-tip bracket. 5. Reinstall the anti-tip wheel. 6. Raise or lower the other anti-tip bracket so that it is at the same height. www.pridemobility.com Jazzy 1121...
  • Page 29 - half when the seat is elevated more than 2.5 - 5 cm (1 - 2 inches). Always check to be sure this system is operating properly before using your power chair Figure 28. Power Elevating Seat Actuator Jazzy 1121 www.pridemobility.com...

  • Page 30: Positioning Belt

    2. Insert the screw through the supplied washer, through the positioning belt and into the seat base for each side of the power chair seat. Figure 29. Positioning Belt Attachment on a Contour 3. Tighten both screws. Seat www.pridemobility.com Jazzy 1121...
  • Page 31 MANDATORY! Inspect the positioning belt for loose or damaged parts before each use of the power chair. If you discover a problem, contact your authorised Pride Dealer for maintenance and repair. Figure 30. Positioning Belt Attachment on a Euro Seat Jazzy 1121 www.pridemobility.com...

  • Page 32: Batteries And Charging

    If the battery charger is exposed to adverse or extreme weather conditions, then it must be allowed to adjust to the difference in environmental conditions before use indoors. Refer to the manual supplied with the battery charger for more information. www.pridemobility.com Jazzy 1121...
  • Page 33 3. Give the batteries another full charge of 8 to 14 hours and operate your power chair again. The batteries will now perform at over 90% of their potential. 4. After four or five charging cycles, the batteries will top off at 100% charge and last for an extended period. Jazzy 1121 www.pridemobility.com...
  • Page 34 Limit baggage weight to essential items. Try to maintain an even speed and avoid stop-and-go driving. Pride recommends charging your batteries for at least 48 continuous hours once per month to improve battery performance and battery life. www.pridemobility.com Jazzy 1121...
  • Page 35 What about shipping? If you wish to use a freight company to ship your power chair to your final destination, repack your power chair in the original shipping container and ship the batteries in separate boxes. Jazzy 1121 www.pridemobility.com...

  • Page 36: Care And Maintenance

    V I I . C A R E A N D M A I N T E N A N C E CARE AND MAINTENANCE Your Jazzy 1121 is a sophisticated power chair. Like any motorised vehicle, it requires routine maintenance checks. You can perform some of these checks, but others require assistance from an authorised Pride Dealer.

  • Page 37: Daily Checks

    Check the rear forks for damage or fluttering which indicates that they may need to be adjusted or have the bearings replaced. See an authorised Pride Dealer for repair. Keep your power chair clean and free of foreign material, such as mud, dirt, hair, food, drink, etc. Jazzy 1121 www.pridemobility.com...

  • Page 38: Cleaning Instructions

    WARNING! When changing a tyre, remove only the centre lug nut and washer, then remove the wheel. If any further disassembly is required, deflate the tyre completely or it may explode. www.pridemobility.com Jazzy 1121...

  • Page 39: Battery Replacement

    WARNING! Do not mix old and new batteries. Always replace both batteries at the same time. To replace the batteries: 1. Turn off the power to the controller. 2. Make sure that the power chair is in drive mode. See III. “Your Power Chair.” Jazzy 1121 www.pridemobility.com...

  • Page 40: Corrective Maintenance

    Disconnect both batteries before load testing and follow the directions that come with the load tester. If either one of the batteries fails the load test, replace both of them. If your power chair still does not power up, contact your authorised Pride Dealer. www.pridemobility.com Jazzy 1121...

  • Page 41: Warranty

    Pride Mobility Products Ltd. cannot be deemed responsible. NOTE: Pride Mobility Products Ltd. provides parts only under warranty. Your authorised Pride Dealer is responsible for labour and service. Please contact your authorised Pride Dealer for information about these services and for any applicable charges.

  • Page 42: Appendix I - Specifications

    Test conducted at maximum weight capacity. NOTE: This product conforms to all applicable ANSI-RESNA testing requirements and ISO 7176 Series EN12184 standards. All specifications subject to change without notice. www.pridemobility.com Jazzy 1121...
  • Page 43 LENGTH W/ FRONT RIGGINGS 110.17 cm (43.38 in.) LENGTH 97 cm (38.125 in.) TURNING RADIUS 57 cm ( 22.5 in. ) WIDTH 55 cm (21.5 in. ) GROUND CLEARANCE 9 cm (3.5 in.) Figure 36. Jazzy 1121 Specification Jazzy 1121 www.pridemobility.com...
  • Page 44 N O T E S www.pridemobility.com Jazzy 1121...
  • Page 45 N O T E S Jazzy 1121 www.pridemobility.com...
  • Page 46 N O T E S www.pridemobility.com Jazzy 1121...
  • Page 47 Quality Control - Jazzy 1121 Inclusion of all Parts Joystick Serial Number Controller Serial Number Left Motor Serial Number Right Motor Serial Number Fit and Finish Performance Pride keeps a more detailed report on file at the factory. Date Inspected...
