Views of Projector Parts

Front-angled View

I
TEM
1.
IR receiver
2.
Lens
3.
Focus ring
4.
Zoom ring
5.
Elevator foot
6.
Function keys
7.
Lamp cover
8.
Vertical lens shift
9.
Horizontal lens shift
10.
Lens release button
L
ABEL
Receives the IR signals from the remote control.
Projection Lens.
Focuses the projected image.
Enlarges the projected image.
Adjusts level of projector.
See Top view—On-screen Display (OSD)
buttons.
Remove cover to replace lamp.
Adjusts the image position vertically.
Adjusts the image position horizontally.
Press the release button before attempting to
replace the lens.
