Serial Communication

The following table describes the serial communication configuration that should be used when
interfacing to CLI via the serial port.
Windows HyperTerminal or ProComm are two tools that can be used to send CLI commands across
the serial port.
Setting
Bits per second
Data bits
Parity
Stop bits
Flow control
Emulation
No Function
AC Power On
1
(Auto power on)
2 Aspect Ratio
3 Auto Image
Auto Off Time
4
No signal power off
5 Auto Source
6 Blank Screen
7 Brightness
Ceiling
8
(Projection mode)
Closed Captions: Non-
9
Muted
10 Color
11 Color Temp
12 Contrast
Value
19200
8
None
1
None
VT100
Command RW Min Max Default Step
APO RW 0
ARZ RW 0
AIM W n/a
AOT RW 0
ASC RW 0
BLK RW 0
BRT RW 0
CEL RW 0
CLC RW 0
CLR RW 0
TMP RW 0
CON RW 0
— 58 —
1 0 1
5 0 1
1 1 1
36 6 1
1 1 1
1 0 1
100 50 1
3 0 1
1 0 1
100 50 1
Source
2 1
Specific
100 50 1
A
PPENDIX
Parameter
0:Disable; 1:Enable
0:Fill
1:4:3
2:16:9
3:Letterbox
4:Native
5:2.35:1
1: Enable
0:Never
1:5 minutes
2:10 minutes
3:15 minutes
...
35:175 minutes
36:180 minutes
0:Disable; 1:Enable
0:Disable; 1 Enable
Display Mode=User1 only
0:Front
1:Rear
2:Ceiling
3:Ceiling+Rear
Off
On (CC1)
Video SVideo only
Display Mode=User only
0:Warm
1:Normal
2:Cold
Display Mode=User1 only
