Communication

The following table describes the serial communication configuration that should be used when
interfacing to the CLI via the serial port.
Windows HyperTerminal or Procomm are two tools that can be used to send CLI commands across
the serial port.
Setting
Bits per second
Data bits
Parity
Stop bits
Flow control
Emulation
No Function
AC Power On
1
(Auto power on)
3 Aspect Ratio
4 Auto Image
5 Auto Off Time
6 Auto Source
7 Blank Screen
9 Brightness
Ceiling
11
(Projection mode)
Closed Captions: Non-
12
Muted
14 Color
15 Color Space
Value
19200
8
None
1
None
VT100
Command RW Min Max Default
APO RW
ARZ RW
AIM W
AOT RW
ASC RW
BLK RW
BRT RW
CEL RW
CLC RW
CLR RW
CSM RW
0 1 0
0 4 0
n/a 1 1
0 36 6
0 1 1
0 1 0
0 100 50
0 3 0
0 1 0
0 100 50
0 2 0
— 56 —
A
PPENDIX
Step Parameter
1 0: Disable; 1: Enable
0:Fill
1:4:3
1 2:16:9
3:Letterbox
4:Native
1 1: Enable
0: Never
1: 5min
2,3...5,
1
6: 30min (Default 6*5=30)
7,8...35,
36: 180min
1 0: Disable; 1: Enable
1 0: Disable; 1: Enable
1 Display Mode=User only
0:Front
1:Rear
1
2:Ceiling
3:Ceiling+Rear
Off
1
On (CC1)
Video SVideo only = satura-
1
tion
Display Mode=User only
0:Auto
1
1:RGB
2:YUV
