OPTIONAL INSTALLATIONS/SETTINGS

I Opening the transceiver case

To remove the transceiver case unscrew the 10
screws (5 in the top panel and 5 in the bottom panel)
as shown in the diagram below.
I UT-102

VOICE SYNTHESIZER UNIT

The UT-102 announces the accessed band's fre-
quency, mode, etc. (S-meter level can also be
announced—p. 55) in a clear, electronically generat-
ed voice, in English (or Japanese).
➀
Remove the top cover as shown above.
➁
Connect the UT-102 as shown in the diagram at
right (label side up).
➂
Replace the top cover.
59
Caution:
Disconnect the DC power cable from
the transceiver before performing any work on the
transceiver.
