SET MODE
Q4 CW PADDLE
This item adjusts the CW paddle type. Four selec-
tions are available.
• n : normal (for electronic keyer use)
• r : reverse (for electronic keyer use)
• buG : When using the electronic key, key down
produces a "dash," releasing the key auto-
matically produces a "dot(s)."
• oFF : Turns OFF the electronic keyer (for
straight key use)
• ud : For using the microphone's [UP]/[DN]
keys instead of the CW paddle.
Q5 ANTI VOX
This item adjusts the ANTI-VOX gain for the VOX
(voice activated transmit) function.
Q5 KEY SPEED
This item adjusts the CW key speed. The key speed
can be selected from 6 to 60 wpm.
Q6 CARRIER Frq
This item adjusts the carrier frequency (BFO frequen-
cy), allowing you to change the audio characteristics.
Selectable values are –200 to +200 Hz in 10 Hz steps.
Q6 RATIO
This item adjusts the CW key ratio (or weight). The
ratio can be selected from 2.8 to 4.5.
Q6 RPTR TONE
This item selects a subaudible tone for FM-T mode
operation to access a repeater. There are 50 tones
available from 67.0 Hz to 254.1 Hz (see table at
right).
Q7 TONE SQL
This item adjusts sets a subaudible tone for tone
squelch use. (the same subaudible tone frequencies
as for repeater operation are available—see above).
49
(CW only)
(SSB/AM/FM only)
(CW only)
(SSB only)
(CW only)
(FM only)
(FM only)
CW
The default is "n," normal.
USB
The default is 5.
CW
The default is 20 wpm.
USB
The default is 0 Hz.
CW
The default is 3.0.
FM
The default is 88.5 Hz.
• Available subaudible tones
67.0 79.9 94.8 110.9 131.8 156.7 171.3 186.2 203.5 229.1
69.3 82.5 97.4 114.8 136.5 159.8 173.8 189.9 206.5 233.6
71.9 85.4 100.0 118.8 141.3 162.2 177.3 192.8 210.7 241.8
74.4 88.5 103.5 123.0 146.2 165.5 179.9 196.6 218.1 250.3
77.0 91.5 107.2 127.3 151.4 167.9 183.5 199.5 225.7 254.1
FM
The default is 88.5 Hz.
Unit: Hz
