Icom I706MKTMG Instruction Manual page 68

12
OPTIONS
SP-7
EXTERNAL SPEAKER
Compact speaker for base station opera-
tion. Height can be adjusted for your con-
venience.
• Input impedance: 8 Ω
• Max. input power: 5 W
SP-21
EXTERNAL SPEAKER
External speaker designed for base station
operation.
• Input impedance: 8 Ω
• Max. input power: 5 W
OPC-581
SEPARATION CABLE
OPC-587
SEPARATION CABLE
Provide front panel detached operation for
mobile installations or compact transceiver
operation.
• OPC-581: 3.5 m (11.5 ft)
• OPC-587: 5 m (16.4 ft)
CR-282
HIGH-STABILITY CRYSTAL UNIT
Contains a temperature-compensating oven heater and crystal unit
for frequency stability.
• Frequency stability: ±0.5 ppm (–10°C to +60°C; +14°F to +140°F)
FL-100
CW NARROW FILTER (500 Hz/–6 dB)
FL-101
CW NARROW FILTER (250 Hz/–6 dB)
FL-103
SSB WIDE FILTER (2.8 kHz/–6 dB)
FL-223
SSB NARROW FILTER (1.9 kHz/–6 dB)
FL-232
CW/RTTY NARROW FILTER (350 Hz/–6 dB)
Two of the above 5 filters can be installed at one time.
HM-103
HAND MICROPHONE
Standard hand microphone.
OPC-599
ADAPTER CABLE
13-pin, ACC connector to 7-pin + 8-pin ACC connector.
65
SP-10
EXTERNAL SPEAKER
SP-12
EXTERNAL SPEAKER
SP-12 SP-10
External speakers suitable for mobile oper-
ation.
SP-12: Slim-type; 8 Ω/3 W
SP-10: Compact-type; 4 Ω/5 W
CT-16
SATELLITE INTERFACE
UNIT
Easy tuning when connecting another Icom
VHF transceiver for instant satellite com-
munications.
OPC-589
MICROPHONE ADAPTER
CABLE
Conversion between 8-pin modular and 8-
pin metal connector for using a desktop
microphone with the IC-706MKIIG.
OPC-742
Required when using both the AT-180 and a 2 m linear
amplifier.
MB-72
Convenient when carrying the transceiver.
UT-102
UT-106
SP-20
EXTERNAL SPEAKER
Equipped with 4 types of audio filters, a
headphone jack and can be connected to 2
transceivers.
• Input impedance: 8 Ω
• Max. input power: 5 W
CT-17
CI-V LEVEL CONVERTER
UNIT
For remote transceiver control using a per-
sonal computer equipped with an RS-232C
port. You can change frequencies, operat-
ing mode, memory channels, etc., via your
computer.
PS-125
DC POWER SUPPLY
Light weight switching regulator system
power supply.
• Output voltage: 13.8 V DC
• Max. current drain: 25 A
ACC 13-PIN CABLE
CARRYING HANDLE
VOICE SYNTHESIZER UNIT
DSP RECEIVE UNIT
