P P R R I I M M A A R R Y Y H H A A R R N N E E S S S S ( ( H H 1 1 ) ) W W I I R R E E C C O O N N N N E E C C T T I I O O N N G G U U I I D D E; Primary Harness Wiring Diagram; Primary Harness Wiring Instructions - Clifford Matrix 1 Installation Manual

What Is Included
➤ ➤ One control module with on-board shock
sensor
➤ ➤
One HF+ receiver/antenna with harness
➤ ➤
Two three-button remote transmitters
➤ ➤
One 514C siren
➤ ➤
One 12-pin primary harness with starter kill
➤ ➤ One plug-in Valet/Program switch
Primary Harness (H1) Wire Connection Guide

Primary Harness Wiring Diagram

___
ORANGE
H1/1
___
WHITE
H1/2
___
WHITE/BLUE
H1/3
___
BLACK/WHITE
H1/4
___
GREEN
H1/5
___
BLUE
H1/6
___
VIOLET
H1/7
___
BLACK
H1/8
___
H1/9 YELLOW
___
H1/10 BROWN
___
H1/11
RED
___
H1/12
RED/WHITE

Primary Harness Wiring Instructions

This guide describes in detail the connection of each wire. Also included are possible applications
of each wire. This system was designed with the ultimate in flexibility and security in mind. Many
of the wires have more than one possible function. Please read carefully to ensure a thorough under-
standing of this unit.
4
➤ ➤ One plug-in LED indicator with bezel
➤ ➤
One 3-pin door lock harness
➤ ➤
Two window decals
➤ ➤
One patent card
➤ ➤
One warranty registration
➤ ➤
One installation guide
➤ ➤ One owner's guide
(-) 500 mA Armed Output
(+)/(-) Selectable Light Flash Output
(-) 200 mA Channel 3 Programmable Output
(-) 200 mA Domelight Supervision Output
(-) Door Trigger Input, Zone 3
(-) Instant Trigger Input, Zone 1
(+) Door Trigger Input, Zone 3
(-) Chassis Ground Input
(+) Switched Ignition Input, Zone 5
(+) Constant Power Input
(-) 200 mA Channel 2 Output
© 2005
Directed Electronics, Inc. all rights reserved
(+) Siren Output
