Clifford Matrix 1 Installation Manual page 16

1. O O p p e e n n a a d d o o o o r r . . (The H1/5 GREEN wire or the H1/7 VIOLET wire must be
connected.)
2. I I g g n n i i t t i i o o n n . . Turn the ignition on, then back off: (The H1/9 YELLOW wire must
be connected.)
3. S S e e l l e e c c t t a a M M e e n n u u . . Press and HOLD the Valet/Program switch: (The
Valet/Program switch must be plugged into the blue port.) After three seconds
the siren will chirp once indicating entry to the Basic Features Menu #1. If this
is the menu you wish to access, release the button and go on to Step 4. If the
button is not released, you will jump to the Advanced Features Menu #2 and
the siren will chirp twice. Once you have selected the desired menu, release the
Valet/Program button and then proceed to Step 4.
4. S S e e l l e e c c t t a a F F e e a a t t u u r r e e . . Press and release the Valet/Program switch the number of
times corresponding to the feature you wish to change. For example, to access
the third feature, press and release the switch three times. Then press the switch
once more and HOLD it. The siren will chirp the number of times equal to
the step you have accessed.
5. P P r r o o g g r r a a m m t t h h e e F F e e a a t t u u r r e e . . While HOLDING the Valet/Program switch, you can
toggle the feature on and off using the remote transmitter. Pressing
will select the one chirp setting. Pressing
setting. (See System Features Menus section of this guide.)
NOTE: Press
than two options.
6. R R e e l l e e a a s s e e t t h h e e V V a a l l e e t t / / P P r r o o g g r r a a m m S S w w i i t t c c h h . .
Once a feature is programmed:
➤ ➤ Other features can be programmed within the same menu.
➤ ➤ Another menu can be selected.
➤ ➤ The learn routine can be exited if programming is complete.
16
to choose the non-default settings for features with more
© 2005
Directed Electronics, Inc. all rights reserved
will select the two chirp
