Clifford Matrix 1 Installation Manual page 23

3. S S e e l l e e c c t t t t h h e e r r e e c c e e i i v v e e r r c c h h a a n n n n e e l l : : Press and release the Valet/Program button the
number of times necessary to access the desired channel.
NOTE: If adding a remote, a button must be taught to the unit in the Channel 1 or Channel 5
position prior to programming other channels.
Press and hold the Valet/Program button once more. The siren will chirp and the LED will blink
the number of times corresponding to the channel that is accessed.
Channel Number
1
2
3
4
5
6
7
8
9
NOTE: Channels 4-6 are only available when using an optional Radar Master remote.
1
NOTE: For Auto Learn Configurations, see Transmitter Configurations section of this guide.
2
3 NOTE: See Channel 9 description in this section.
4. P P r r e e s s s s t t h h e e t t r r a a n n s s m m i i t t t t e e r r b b u u t t t t o o n n : : While HOLDING the Valet/Program switch,
press the button from the transmitter that you wish to assign to the selected
channel. The unit will chirp once indicating that the channel has been entered.
5. P P r r e e s s s s t t h h e e s s a a m m e e t t r r a a n n s s m m i i t t t t e e r r b b u u t t t t o o n n a a g g a a i i n n : : While still HOLDING the
Valet/Program switch, press the same transmitter button that you just
programmed. The siren will chirp twice to confirm that the desired channel has
been successfully programmed to the transmitter button. If this step is not
performed, the channel will not be programmed to the transmitter button. It
is not possible to teach a transmitter button to the system more than once.
6. R R e e l l e e a a s s e e : : Once the code is learned, the Valet/Program button can be released.
www.clifford.com
Function
Arm/Disarm/Panic
Silent Mode/Remote Valet/Trunk Release
Remote Start or other accessories
Arm only (only available with Radar Master remote)
Disarm only (only available with Radar Master remote)
Panic only (only available with Radar Master remote)
Auto-learn 3-Button Transmitter Configuration
Auto-learn 4-Button Transmitter Configuration
Zap (delete all transmitters)
2
2
3
Wire Color
RED/WHITE
WHITE/BLUE
1
1
1
23
