C C h h a a n n n n e e l l s s 4 4 - - 6 6 (available only when using a Radar Master remote)

Channels 4 through 6 are used to assign the arm, disarm and panic functions to separate buttons

on the remote control. These channels are only available when using an optional Radar Master

remote. (See Transmitter Configurations section of this guide.) Teaching a transmitter button to

Channel 4 erases all previous programming from the transmitter's memory. Similarly, if the trans-

mitter is set up to use the separate arm, disarm and panic channels and a button from that

transmitter is programmed to Channel 1, the transmitter's memory will be erased, and the system

will only recognize the button that was programmed to Channel 1.

C C h h a a n n n n e e l l # # 9 9 : : If any button from a known transmitter is programmed to Channel 9, all transmitters

will be erased from memory and the system features will revert to the default settings. This is useful

in cases where the one of the customer's transmitters is lost or stolen. This will erase any lost or

stolen transmitters from the system's memory. It can also be used to start from scratch if the trans-

mitter buttons were programmed incorrectly.

5. R R e e l l e e a a s s e e . . Once the code is learned, the Valet/Program button can be released.

To exit the learn routine:

One long chirp indicates that Learn Routine has been exited. Learn Routine will be exited if any of

the following occurs:

➤ ➤

Ignition is turned off.

➤ ➤

Door is closed.

➤ ➤

Valet/Program button is pressed too many times.

➤ ➤

More than 15 seconds elapse between steps.

Transmitter Configurations

Using the Auto Learn functions in the Transmitter/Receiver Learn Routine, the transmitters can be

programmed either with the 3-button (standard) configuration or 4-button configuration, which

requires an optional 4-button transmitter.
