About This Guide
This document shows how to use the RocketIO™ GTP transceivers in Virtex™-5 FPGAs.
Complete and up-to-date documentation of the Virtex-5 family of FPGAs is available on
the Xilinx website at http://www.xilinx.com/virtex5.

Guide Contents

This manual contains the following chapters and appendices:
•
•
•
Virtex-5 RocketIO GTP Transceiver User Guide
UG196 (v1.3) May 25, 2007
"Section 1: FPGA Level Design"
♦
Chapter 1, "Introduction to the RocketIO GTP Transceiver"
♦
Chapter 2, "RocketIO GTP Transceiver Wizard"
♦
Chapter 3, "Simulation"
♦
Chapter 4, "Implementation"
♦
Chapter 5, "Tile Features"
♦
Chapter 6, "GTP Transmitter (TX)"
♦
Chapter 7, "GTP Receiver (RX)"
♦
Chapter 8, "Cyclic Redundancy Check (CRC)"
♦
Chapter 9, "Loopback"
♦
Chapter 10, "GTP-to-Board Interface"
"Section 2: Board Level Design"
♦
Chapter 11, "Design Constraints Overview"
♦
Chapter 12, "PCB Materials and Traces"
♦
Chapter 13, "Design of Transitions"
♦
Chapter 14, "Guidelines and Examples"
"Section 3: Appendices"
♦
Appendix A, "MGT to GTP Transceiver Design Migration"
♦
Appendix B, "OOB/Beacon Signaling"
♦
Appendix C, "8B/10B Valid Characters"
♦
Appendix D, "DRP Address Map of the GTP_DUAL Tile"
♦
Appendix E, "Low Latency Design"
