1. Introduction

This equipment is an analog RGB signal input, color TFT LCD for
use in combination with a host computer such as the CONTEC IPC
Series or single-board computer (SBC).

Features

- Full-bright, wide-angle-of-visibility type of liquid crystals capable
of displaying up to 16,777,216 colors(15inch), 262,144
colors(10inch / 12.1inch)
- Standard analog RGB input for screen. RS-232C and USB
interfaces for touch panel.
- Multiple touch panel configurations containing up to eight touch
panels are supported when using the USB touch panel interface.
- Auto-scaling feature that resizes the input screen to the LCD dot
configuration.
- On-screen display setup menu facilitating screen adjustment
- Analog touch panel enabling mouse emulation using driver
software
- Input connector allowing external control of turning on/off the
backlight
- Back-mounted, dedicated power supply unit [IPC-POA200/12-01]
and AC adapter [IPC-ACAP12-01] available as an option,
enabling the LCD to be used with an AC power supply
- Front structure with IP65-compliant ingress protection
- Optional stand kit for tabletop use
* For the host computer to be used with the display or its options,
contact your local CONTEC branch or sales office.
