xStack DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Web UI Reference Guide
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
Click the Apply button to accept the changes made.

Initialize Host-based Port(s)

This window is used to initialize the 802.1X authentication state machine of host-based ports.
This window appears when the Authentication State is enabled in 802.1X Global Settings window.
To view this window, click Security > 802.1X > Initialize Host-based Port(s) as shown below:
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
MAC Address
Click the Apply button to accept the changes made.

Reauthenticate Port-based Port(s)

This window is used to re-authenticate the device connected with the port-based ports and display the current
status of the re-authenticated port-based port(s).
This window appears when the Authentication State is enabled in 802.1X Global Settings window.
To view this window, click Security > 802.1X > Reauthenticate Port-based Port(s) as shown below:
The fields that can be configured are described below:
Parameter
Unit
From Port / To Port
Description
Select a unit you want to display.
Use the drop-down menus to select a range of ports to initialize.
Figure 9-19 Initialize Host-based Port(s) Window
Description
Select a unit you want to display.
Use the drop-down menus to select a range of ports to initialize.
Tick the check box and enter the MAC address of the Switch connected to the
corresponding port, if any.
Figure 9-20 Reauthenticate Port-based Port(s) Window
Description
Select a unit you want to display.
Use the drop-down menus to select a range of ports to re-authenticated.
395
