IS SERIES
Commercial & Security Video Intercom system
Local System
SETTING MANUAL
Thank you for selecting Aiphone for your communication and security needs. Please read this manual and the separate
"OPERATION MANUAL" carefully before setting and using this system.
Refer to the provided "INSTALLATION MANUAL" for complete information regarding this system.
*
IMPORTANT
Please read and understand the system setting procedures before beginning the setup process.
Please note that images and illustrations depicted in this manual may differ from the actual ones.
834171 E 0513AZ

Advertisement

Table of Contents
loading

Related Manuals for Aiphone IS SERIES

Summary of Contents for Aiphone IS SERIES

  • Page 1 Local System SETTING MANUAL Thank you for selecting Aiphone for your communication and security needs. Please read this manual and the separate “OPERATION MANUAL” carefully before setting and using this system. Refer to the provided “INSTALLATION MANUAL” for complete information regarding this system.

  • Page 2: Table Of Contents

    CONTENTS ABOUT THIS MANUAL ....3 Setting time and date [Time and date setting] ....19 PURPOSE OF THE SYSTEM Settings under SETTINGS ........3 [OPTIONAL FUNCTION MENU] ... 20 SETTING LIST ......... 4 Registering sound fi les for chime [Chime setting –...

  • Page 3: About This Manual

    ABOUT THIS MANUAL The IS system provides various manuals to meet various system planning and work processes. Use the manuals necessary for your system. Manual confi gurations The following manuals are provided for a local system. Read all the manuals for installing, setting up, and using a local system, or provide the manuals to the persons working with the system.

  • Page 4: Setting List

    443 (Unmodifi able) Administrator New administrator ID - Up to 16 alphanumeric characters setting Current Password Up to 16 alphanumeric characters - (aiphone) New Password Up to 16 alphanumeric characters New Password Up to 16 alphanumeric characters (Re-type) System setting Area registration...
  • Page 5 Title Sub title Item Sub item Setting range Default System setting Advanced station Video door station Call priority Normal/Priority/Urgent Normal settings /Audio door station Called stations (Set up to 20 master stations from (Some are set by /Room sub station the registered ones.) default.)* Contact type...
  • Page 6 Title Sub title Item Sub item Setting range Default System setting Advanced station Room sub (Contact output terminal) L1 to L4 settings control unit/ Contact type Normally open (NO)/Normally closed Normally open Add-on control (NC) (NO) unit Trigger condition None/Calling notice/Door release/PA None output Calling notice...
  • Page 7 Title Sub title Item Sub item Setting range Default OPTIONAL FUNCTION MENU Chime setting Registering sound (Sound fi le) SF1 to SF15 (3MB in total, 2MB/fi le) - source Registering sound Sound number SS1 to SS20 sequences Sound sequence Up to 24 alphanumeric characters name Step 1 to 10...
  • Page 8 Title Sub title Item Sub item Setting range Default Timer setting Call Normal/Priority/Urgent 10 to 600 (sec.), 0 (Unlimited) Normal: 30 (sec.) Priority: 90 (sec.) Urgent: 0 (Unlimited) Communication In Local (local system only) 30 to 600 (sec.) 60 (sec.) Paging 30 to 600 (sec.) 60 (sec.)

  • Page 9: Starting Up The System

    STARTING UP THE SYSTEM Before making the system settings, confi rm that a PC is connected to the central control unit (IS-CCU). The system settings are made on the PC by accessing the web browser for the settings incorporated with the central control unit (IS-CCU). NOTE: When you fi...

  • Page 10: Setting The System Confi Guration [System Confi Guration]

    The login window of the web browser is displayed. Log in to the system by setting the following items. • Select language Select the language for displaying contents on the setting windows. • Enter “aiphone”. • Password Enter “aiphone”. Login • Click Login to display the setting window.

  • Page 11: Making The System Settings

    MAKING THE SYSTEM SETTINGS The basic setting procedure When you have logged in to the system, the setting window appears. You can make the settings on this window. Make sure to refer to the on-screen instructions and comments displayed on each window when you make the settings. Depending on the PC and its OS or environment, the display may differ.

  • Page 12: Settings Under [System Installation Menu]

    The following shows the setting procedure for the items of each title. Refer to “SETTING LIST” (→P. 4-8) for details about the settings. Make the settings by also referring to the on-screen instructions. Settings under [SYSTEM INSTALLATION MENU] • [Unit name]: Making network settings [Network setting] Enter a name for this unit.

  • Page 13: Setting The Administrator Id And Password [Administrator Setting]

    Up to 99 areas can be registered. “aiphone” is preset as the default for both ID and password. Click Area registration in the table of contents.

  • Page 14: Registering Zones [System Setting - Zone Registration]

    Registering zones Registering control units [System setting [System setting – Zone registration] – Control units composition] Register zones for paging (transmitting announcements and Register all the control units connected to the central control chime). The number to which a name is entered is registered unit.

  • Page 15: Registering Stations And Pa Outputs [System Setting - Registering Stations]

    Registering stations and PA outputs Station number • [System setting – Registering stations] Click to assign sequential numbers to all the checked stations from top to bottom. The number you enter will Register all the stations and PA outputs connected in the be set as the fi...

  • Page 16: Making Detailed Settings To Stations And Control Units [System Setting - Advanced Station Settings]

    Making detailed settings to stations and Making detailed settings to door stations or room sub stations control units [System setting – Advanced station settings] NOTE: Make the settings to door stations or room sub stations Make detailed settings for the registered stations and control respectively.

  • Page 17: Making Detailed Settings To Master Stations

    Settings on [Contact input] window (for room Making detailed settings to master sub stations only) stations Make settings for contact input. The following setting item buttons are displayed in the • [Contact type]: “Advanced settings” window. Select either Normally open (NO) or Normally closed (NC). •...

  • Page 18: Making Detailed Settings To The Central Control Unit, Add-On Control Unit(S) Or Room Sub Control Unit(S)

    • [Sound source]: Making detailed settings to the central control Select either [Internal sound source] or [External unit, add-on control unit(s) or room sub sound source] as the source of chime. When [Internal sound source] is selected, select a sound fi le or control unit(s) sequence from the registered ones in the list.

  • Page 19: Registering Stations And Pa Outputs To Zones [System Setting - Zone Setting]

    Registering stations and PA outputs to zones Setting time and date [System setting – Zone setting] [Time and date setting] Assign stations and PA outputs to the registered zones. Set the time and date of the system, used for chime schedule and transfer schedule.

  • Page 20: Settings Under [Optional Function Menu]

    Settings under [OPTIONAL FUNCTION MENU] Registering sound fi les for chime Registering sound sequences [Chime setting – Registering sound source] [Chime setting – Registering sound sequences] Register sound data as the source of each chime. Copy MP3- Register sound sequences for chime. format sound fi...

  • Page 21: Registering Daily Chime Schedule

    Registering daily chime schedule Setting chime schedule [Chime setting – Registering daily chime schedule] [Chime setting – Chime schedule setting] Up to 10 daily schedules can be registered. You can set a weekly chime schedule or individual daily schedule. Click Registering daily chime schedule in the table * The settings can be made to 1 year ahead.

  • Page 22: Registering Daily Transfer Schedule

    Settings on [Weekly schedule] setting window Registering daily transfer schedule Select either [Every week] or [Every other week]. [Transfer setting – Registering daily Set the schedule start and end dates. transfer schedule] The monthly calendar is displayed by clicking Refer calendar and you can select the start and You can set the schedule for transferring calls to other master end dates.

  • Page 23: Setting Transfer Schedule

    Settings on [Weekly schedule] setting window Setting transfer schedule Select either [Every week] or [Every other week]. [Transfer setting – Transfer schedule setting] Set the schedule start and end dates. You can set a weekly transfer schedule and individual daily The monthly calendar is displayed by clicking schedule.

  • Page 24: Setting The Timer [Timer Setting]

    Setting the timer [Timer setting] Set the time for each operation. Click Timer setting in the table of contents. Set the time for the following operations respectively. The setting range is displayed on the right side of each input box. •...

  • Page 25: Settings Under [Updating System Settings]

    Settings under [UPDATING SYSTEM SETTINGS] Updating the system Downloading setting data onto the PC [Updating the system] [Downloading setting data] Update the system with the setting data you have entered You can download the setting data you have made into a fi le (currently stored temporarily).

  • Page 26: Maintenance

    You can reset the system settings to factory default. ■ Downloading updated fi rmware data Please access our website at http://www.aiphone.net/ and Access the web browser and log in. download the fi rmware data on the PC to update the system.
  • Page 27 AIPHONE CO., LTD., NAGOYA, JAPAN...
