Aiphone IS SERIES Setting Manual

Commercial & security ip video intercom system; network direct system
Hide thumbs Also See for IS SERIES:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual, Setting Manual
IS SERIES
Commercial & Security IP Video Intercom system
Network Direct System
SETTING MANUAL
Thank you for selecting Aiphone for your communication and security needs. Please read this manual and the separate
"OPERATION MANUAL" carefully before setting and using this system.
Refer to the provided "INSTALLATION MANUAL" for complete information regarding this system.
*
IMPORTANT
Please read and understand the system setting procedures before beginning the setup process.
Please note that images and illustrations depicted in this manual may differ from the actual ones.
FK1629 D 0513AZ

Advertisement

Table of Contents
loading

Related Manuals for Aiphone IS SERIES

Summary of Contents for Aiphone IS SERIES

  • Page 1 Network Direct System SETTING MANUAL Thank you for selecting Aiphone for your communication and security needs. Please read this manual and the separate “OPERATION MANUAL” carefully before setting and using this system. Refer to the provided “INSTALLATION MANUAL” for complete information regarding this system.

  • Page 2: Table Of Contents

    CONTENTS ABOUT THIS MANUAL ....3 Making detailed settings to door stations ..........23 PURPOSE OF THE SYSTEM Making detailed settings to master SETTINGS ........3 stations ..........24 SETTING LIST ......... 4 Registering stations to zones [System setting – Zone setting] ..25 SYSTEM SETTING FLOW ....

  • Page 3: About This Manual

    ABOUT THIS MANUAL The IS system provides various manuals to meet various system planning and work processes. Use the manuals necessary for your system. Manual confi gurations The following manuals are provided for a network direct system. Read all the manuals for installing, setting up, and using a network direct system, or provide the manuals to the persons working with the system.

  • Page 4: Setting List

    Web port 443 (Unmodifi able) Connection port IPv4 1024 - 65535 5060 IPv6 5060 (Unmodifi able) Connection Up to 16 alphanumeric characters aiphone Password Network setting: UPnP IPv4 ON/OFF Common IPv6 (Unmodifi able) Global IP address IPv4 0 - 255 (for each fi eld) (available when IPv6 (Unmodifi...
  • Page 5 Default Administrator New administrator ID - Up to 16 alphanumeric characters setting Current Password Up to 16 alphanumeric characters - (aiphone) New Password Up to 16 alphanumeric characters New Password Up to 16 alphanumeric characters (Re-type) IP unit search System setting Area/Site...
  • Page 6 Title Sub title Item Sub item Setting range Default Time and date Set current time Manual setting Year: 2009 to 2099 (Internal time of setting Month: 1 to 12 the IP Host unit) Day: 1 to 31 Hour: 0 to 23 Minute: 0 to 59 Second: 0 to 59 Synchronized with PC...
  • Page 7 Title Sub title Item Sub item Setting range Default Remote site Remote site master Normal/Priority/Urgent (Select one from the registered pilot call setting call stations in your site for each of “Normal”, “Priority” and “Urgent”.) Remote site door call Normal/Priority/Urgent (Select up to 20 stations from the registered master stations in your site for each of “Normal”, “Priority”...

  • Page 8: System Setting Flow

    All IP devices on your network should use either IPv4 or IPv6, but not a mix of both. • In an IPv4 network environment, you can fi nd additional information about network settings on our website at http://www.aiphone.net/. • (Our website does not support IPv6.) The network setting methods differ depending on the IP version used in your network.

  • Page 9: [Network Diagnostic Fl Owchart For Ipv4 ]

    In that case, set [UPnP] to OFF at [Network setting: Common] (→P. 19) and then make settings on the router again by confi rming the settings at [IP unit registration] (→P. 21). See http://www.aiphone.net/ for a list of routers that have been tested with UPnP.

  • Page 10: [Network Diagnostic Fl Owchart For Ipv6 ]

    [Network diagnostic fl owchart for IPv6 ] Select either from the chart below, then start the network settings by following the Flow 1 Flow 2 selected fl ow. START Do you have a router that supports stateless address autoconfi guration in the network? Flow 1 Flow 2 (IP host unit: A static IP address is set,...

  • Page 11: Flow 1

    Flow 1 (IP host unit: A static IP address is set, IP client units: IP addresses are assigned automatically by the DHCP server (when IPv4 is used) or stateless address autoconfi guration (when IPv6 is used)) * This is the outline of setting fl ow. Also make the detailed settings on each setting window referring to the corresponding pages. START : Settings on the IP host unit Write down the MAC addresses of all the IP units to be used...

  • Page 12: Flow 2

    Flow 2 (All units: Static IP addresses are set) <When IPv4 is used>: Select this method when you do not have a DHCP server in your network. <When IPv6 is used>: Select this method when you do not have a router that supports stateless address autoconfi...

  • Page 13: Flow 3

    Flow 3 (only when is used) IPv4 (All units: IP addresses are assigned automatically by the DHCP server) This is the outline of setting fl ow. Also make the detailed settings on each setting window referring to the corresponding pages. START : Settings on the IP host unit Write down the MAC addresses of all the IP units to be used...

  • Page 14: Remote Site Connection Settings

    Remote site connection settings You need to make the remote site connection settings to enable communication between your site and remote sites. Make the settings by following the procedure below after the network settings for your site have fi nished. * This is the outline of setting fl...

  • Page 15: Starting Up The System And Preparing For The Settings

    STARTING UP THE SYSTEM AND PREPARING FOR THE SETTINGS The system settings are mainly made on the PC by accessing the web browser for the settings incorporated with the IP unit as the IP host unit. It is recommended to use only one PC for the settings that is connected to the system. NOTE: When you fi...
  • Page 16 Default: https://192.168.0.40 192.168.0.40/ After selecting English as the target language, the login window of the web browser is displayed. Log in to the system by setting the following items. • Enter “aiphone”. • Password Enter “aiphone”. Login • Click Login to display the setting window.

  • Page 17: The System Setting Details

    THE SYSTEM SETTING DETAILS The basic setting procedure When you have logged in to the system, the setting window appears. You can make the settings on this window. Make sure to refer to the on-screen instructions and comments displayed on each window when you make the settings. Depending on the PC and its OS or environment, the display may differ.

  • Page 18: Settings Under [System Installation Menu]

    The following shows the setting procedure for the items of each title. Refer to “SETTING LIST” (→P. 4-7) for details about the settings. Make the settings by also referring to the on-screen instructions. Settings under [SYSTEM INSTALLATION MENU] Making network settings to each IP unit <When "IP version"...

  • Page 19: Making Network Settings For The Whole System [Network Setting: Common]

    This setting can be made to each of the IP units in your site. Click Network setting: Common in the table of “aiphone” is preset as the default for both ID and password. contents. Click Administrator setting in the table of contents.

  • Page 20: Confi Rming The Ip Units Connected To The System [Ip Unit Search]

    Confi rming the IP units connected to the Registering areas and remote sites system [IP unit search] [System setting – Area/Site registration] Required Before confi guring system wide settings, confi rm the IP units are connected to the network, and set the network Register areas (for separating stations in your site) and/ setting for each IP unit using [IP unit search].

  • Page 21: Registering Zones [System Setting - Zone Registration]

    Registering zones Registering IP units [System setting – Zone registration] [System setting – IP unit registration] Register zones for paging (transmitting announcements) in Register IP units by selecting from the connected ones to the your site. The number to which a name is entered is registered system.

  • Page 22: Registering Stations [System Setting - Registering Stations]

    How to select multiple stations Registering stations ○ Click to check the stations you will register. [System setting – Registering stations] Register all the stations connected in the system, and set the area, station no. and station name to them. Click Registering stations in the table of contents.

  • Page 23: Making Detailed Settings To Stations [System Setting - Advanced Station Settings]

    Making detailed settings to stations Making detailed settings to door [System setting – Advanced station settings] stations Make detailed settings for the registered stations. The settings The following setting item buttons are displayed in the can be made to a station individually, or multiple stations of the “Advanced settings”...

  • Page 24: Making Detailed Settings To Master Stations

    Settings on [Other] window Making detailed settings to master • [Transmit volume boost at PTT]: stations Select whether to increase the press-to-talk sound volume transmitted to the stations (ON) or not (OFF). The following setting item buttons are displayed in the •...

  • Page 25: Registering Stations To Zones [System Setting - Zone Setting]

    Registering stations to zones Setting time and date [System setting – Zone setting] [Time and date setting] Assign stations to the registered zones. Set the time and date of the system, used for transfer schedule. Click Zone setting in the table of contents. Click Time and date setting in the table of contents.

  • Page 26: Settings Under Optional Function Menu]

    Settings under [OPTIONAL FUNCTION MENU] Registering daily transfer schedule Setting transfer schedule [Transfer setting – Registering daily [Transfer setting – Transfer schedule setting] transfer schedule] You can set a weekly transfer schedule and individual daily You can set the schedule for transferring calls to other schedule.

  • Page 27: Setting The Timer [Timer Setting]

    Settings on [Weekly schedule] setting window Setting the timer [Timer setting] Select either [Every week] or [Every other week]. Set the time for each operation. Set the schedule start and end dates. Click Timer setting in the table of contents. The monthly calendar is displayed by clicking Refer calendar and you can select the start and end dates.

  • Page 28: Paging From Remote Sites Remote Site Pilot Call Setting]

    Settings on [Remote site master call] setting Setting stations to receive calls and window zones to receive paging from remote sites You can set a station (master station or door station) that [Remote site pilot call setting] receives a call from a master station in a remote site. One station can be set for each priority.

  • Page 29: Video Setting

    Video setting E-mail setting Click Video setting in the table of contents. You can send an e-mail when calling or send error messages etc. by e-mail. Up to 3 mail addresses can be set. Set the following settings for video quality. NOTES: •...

  • Page 30: Updating System Settings]

    Settings under [UPDATING SYSTEM SETTINGS] Updating the system Downloading setting data onto the PC [Updating the system] [Downloading setting data] Update the system with the setting data you have entered You can download the setting data you have made into a fi le (currently stored temporarily).

  • Page 31: Maintenance

    You can reset the system settings to factory default. ■ Downloading updated fi rmware data Please access our website at http://www.aiphone.net/ and Access the web browser and log in. download the fi rmware data on the PC to update the system.

  • Page 32: Setting Information Memo

    Setting Information Memo Record your settings information. It will need when resetting or maintenance. Host unit Network setting: Individual Static IP Address Subnet Mask Default Gateway Primary DNS Server Secondary DNS Server MAC address Unit name Connection port Connection Password Network setting: Common Global IP address Connection port: global...
  • Page 33 AIPHONE CO., LTD., NAGOYA, JAPAN...
