Tear-Off with
Quick-Load
(Straight-through)
1
Remove any empty core from the media supply
Intermec EasyCoder F4 – Installation & Operation Ed. 3
In addition to the media load procedure for tear-off (straight-through)
operation described earlier in this chapter, the EasyCoder F4 can
optionally be fi tted with a set of Quick-Load guides that makes
media load much easier and quicker, especially if the printer
has a short side door. See Chapter 10, "Options" for installation
instructions.
The printer is normally delivered with two different sets of Quick-
Load guides: wide and narrow. The wide type generally guides the
media better, but the media must be at least 80 mm (3.15 inches)
wide. The narrow type allows a media width as narrow as 40 mm
(1.57 inches), but it may be less suited for wide and thin media.
Illustrations in this chapter show the narrow type of guides.
Quick-Load cannot be combined with peel-off (self-strip) opera-
tion.
Use the <Feed> key (see fi gure #5) when loading the same type of
media. When switching to a new type of media, or if the printer does
not feed out the media properly, simultaneously press the < Shift>
and <Feed> keys to perform a "testfeed".
Fully automatic loading, without the operator having to press any
key, requires a special set of Intermec Fingerprint instructions in
the application program.
roll post.
2
Fit a new roll of media on the supply post and
adjust the edge guide so the roll becomes fl ush
with the center section.
Chapter 5 Media Load
33
