Front View

Control Lamps
Display Window
Keyboard
Print Key
Print Mechanism
Intermec EasyCoder F4 – Installation & Operation Ed. 3
At the front of the printer are the display window, the control lamps,
and the keyboard. These features allow the operator to control
and set up the printer manually, in addition to the remote control
facilities offered by the Intermec Fingerprint programming language
and Intermec Shell.
The printed labels, tickets, or tags are presented at the front of
the print mechanism.
Chapter 3 Installation
Side Door
