Delay For HDD (Secs)
This item allows you to set longer time stand by before system Scan HDD at post
screen. Some HDD may need a longer stand by time before it can be detected.
Options: 0 ~ 15.
OnChip IDE Channel 0/1
The mainboard supports two channel of ordinary IDE interface and one channel of
serial ATA interface. Select "Enabled" to activate each channel separately.
If you do not use the onboard IDE connector, set the Onboard Primary (Secondary)
PCI IDE to "Disabled".
Primary/Secondary Master/Slave UDMA
Select the mode of operation for the IDE drive. Ultra DMA-100/133 implementation
is possible only if your IDE hard drive supports it and the operating environment
includes a DMA driver. If your hard drive and your system software both support
Ultra DMA-100/133, select Auto to enable UDMA mode by BIOS.
Options: Auto, Disabled.
SATA 3/4
This item enables/disables the S-ATA3/4 ports.
SATA 1/2
This item enables/disables the S-ATA1/2 ports.
RAID Enable
This item allows you to select the RAID mode. When set to "Enabled" the four
fields become available to set RAID for each SATA.
Options: Enabled, Disabled.
BIOS
Page 4-11
