CFPA: Front Panel Audio Connector
When the jumpers are removed this connector can
be used for front panel audio. The front panel
phone jack should have "normal close" switch.
Without phone plug inserted, the rear panel audio is
enabled. With phone plug inserted, the rear panel
audio will be disabled.
MIC_In
NC
Front Line-out-R
Front Line-out-L
CD-IN/AUX-IN: CD Audio_IN Connector
The CD-IN and AUX-IN connectors are used to
receive audio form a CD-ROM drive, TV tuner or
MPEG card.
SATA1 ~ SATA4: Four Serial ATA Connectors
These connectors enable you to connect Serial
ATA HDDs or optical drives type.
SATA4
SATA1
2
1
Settings:
GND
Pins (5-6) & (9-10) Short (default):
+5V
Only the onboard rear panel audio
Rear Line-out-FR
jack can be used.
Key
Pins (5-6) & (9-10) Open:
Rear Line-out-FL
Only front panel audio jack can be
9
10
used.
CD-IN
CD_IN_Right
CD_Reference
1
CD_IN_Left
GND
B+
B-
A-
A+
GND
GND
Installation
AUX-IN
AUX_IN_Right
GND
1
AUX_IN_Left
1
Page 3-9
