AT810 Series User Manual
press it.
21 Press "Hold" to hold the call when talking, once more to recover.
22 Mute key:
Press "Mute", user could hear the voice from the other end but he
could not get any voice from user.
23 Voice volume key:
 "+" for turning up the volume unless the volume is the loudest
yet.
 "-" for turning down the volume unless the volume is the
lowest yet.
24 Numeral keys.
25 Handfree button:
Press to enter handfree mode.
26 Dial button:
 When finish dialing the telephone number, press this button to
send out the phone number.
 After lifting the phone, this button can act as redial key.
27 Del button:
Press to delete a single number or letter.
28 Headset button:
Press to enter headset answering mode.

3. Menu Operation

Press "Menu/Enter" to enter menu, there will be two modes to select when it displays
"INPUT PASSWORD" on LCD:
1. If user input the password (which defaults to 123), it's the admin mode;
2. If user do not input password but press "Menu/Enter" directly, it's the user mode,
user have no rights to configure anything but browse them.
If the password is error, it will display "INPUT AGAIN 2" on LCD. Please press Menu/Enter
key to input the password again. If user input the incorrect password three times, the
phone will return to idle state automatically. If user wants to modify the configurations
via phone, "De" button is needed to be pressed firstly, and then user can set a new value,
and press "Menu/Enter" to save it.
Level 1 Menu
NETWORK
ATCOM TECHNOLOGY CO., LIMITED
Level 2 Menu
NET MODE
Level 3 Menu
DHCP ON
PPPOE
www.atcom.cn
Level 4 Menu
14
