1.11.2 Wall position

A. Put the bottom side of the IP phone upside and push the plate with letter "PUSH" into
the slot, please refer the picture as below:
B. Push the other plate into the slot in accordance with the direction of the arrow.
C. Repeat A and B. It is the picture of wall mounting after fixing the two feet below:
D. Disassemble the feet way:
Press the plate with word "PUSH" and pull the feet with the direction of arrow. When the
plate is pull out of the slot (there will be a sound of "pa") user can take off the feet.
ATCOM TECHNOLOGY CO., LIMITED
Attention: Please rotate the hook to the
position as in picture with a coin or other
tools
