Open/Close Reports must be enabled in Locations
333 and 334 (refer to Section 15.6 Open/Close Reports on
page 61) for this option to work.
4 – Delay Siren until Transmission Complete
If this option is selected, the EDMSAT, horn speaker,
bell, and strobe outputs are not activated until after
the control panel sends the message and the base
station receiver sends a kiss-off back to the control
panel. If multiple messages are sent, the sirens are
activated after the last kiss-off is sent.
If a Codepad Panic, Codepad Fire, or Codepad
Medical Alarm is activated, the EDMSAT, horn
speaker, bell, and strobe outputs operate immediately.
8 – Extend Time to Wait for Handshake from 30 to
60 Sec
By default, the control panel waits approximately 30
sec for receipt of a valid handshake tone after it dials
the monitoring station. The handshake tone indicates
to the control panel that it reached the monitoring
station and can now send its messages. Selecting this
option extends this wait time from 30 sec to 60 sec.
12.3
Dialer Options 3
Program the selected Dialer Options 3 in
Location 179.
The default is 0. The options are:
1 – Set DTMF Dialing Pulses to 1 Digit/Sec
If this option is not selected, the Australian DTMF
dialing format dials at 5 digits per sec (that is, 100 ms
tone, 100 ms pause, 100 ms tone, 100 ms pause).
If this option is selected, the Australian DTMF dialing
format dials at the rate of 1 digit per sec (that is, 500
ms tone, 500 ms pause).
2 – Reserved
4 – Change Decadic Dialing to 60/40
Some countries have different requirements for
decadic dialing. Selecting this option changes the
dialing characteristics from 65/35 (Australian
Standard) to 60/40. Select this option only when the
control panel is used in a country that requires
decadic dialing as 60/40. This option has no effect
when using DTMF tone dialing.
8 – Reserved
12.4
Alarm Link Options
For more information about this location, refer to
Section 8.2 Alarm Link Options on page 40.
13.0 Access Code
This section describes the access codes that assign
privileges and access functions for User Code holders
of the system. There are two types of access codes,
the Installer Code and User Codes. Each code allows
access and operation of control panel functions.
Bosch Security Systems, Inc. | 12/08 | F01U089401-02
ICP-CC404 | Installation Guide | 13.0 Access Code
13.1
Installer Code
Program the Installer Code in Locations 181 to 184.
The default Installer Code is 1 2 3 4.
Use this code to access Installer's Programming
Mode. The Installer Code can be up to four digits
long. After power is applied to the control panel, the
Installer Code can disarm the system if it is the first
code used. The next time the Installer Code is used
enables access to Installer's Programming Mode.
Installer Code functions allow the installer to execute
functions when the system is disarmed without the
customer's Master Code. Refer to Section 6.1 Installer
Code Functions on page 27 for more information.
Refer to Section 2.1 Programming with the Remote
Codepad on page 9 for more information on
programming the system.
13.2
User Codes
The purpose of User Codes is to arm and disarm the
system and to perform other specific functions. A
Master Code holder can change or delete User Codes.
Program User Codes 1 to 8 in Locations 185 to 224.
Program Remote Radio User Codes 9 to 16 in
Locations 225 to 264.
The default User Codes are listed in Table 40.
Table 40:
Default User Codes
User Number
Locations
User #01
185 to 189
User #02
190 to 194
User #03
195 to 199
User #04
200 to 204
User #05
205 to 209
User #06
210 to 214
User #07
215 to 219
User #08
220 to 224
RF User #09
225 to 229
RF User #10
230 to 234
RF User #11
235 to 239
RF User #12
240 to 244
RF User #13
245 to 249
RF User #14
250 to 254
RF User #15
255 to 259
RF User #16
260 to 264
Code
Priority
2
5
8
0
10
15 15 15 15
2
15 15 15 15
2
15 15 15 15
2
15 15 15 15
2
15 15 15 15
2
15 15 15 15
2
0
15 15 15
3
15 15 15 15
2
15 15 15 15
2
15 15 15 15
2
15 15 15 15
2
15 15 15 15
2
15 15 15 15
2
15 15 15 15
2
15 15 15 15
2
51
